2022 - Genie GTH5519 Telehandler()
- Listing No
- 211110
- Year
- 2022
- Manufacturer
- Genie
- Model
- Condition
- Used
- Location
- USA
- Price
- $59,000
- Description
-
All listed inventory is in stock and ready for immediate purchase. Financing and delivery is available on all inventory purchases. Dimensions A Length To Fork Face 13.13ft in E Ground Clearance 1.19ft in B Width Over Tires 5.91ft in C Overall Height 6.5ft in D Wheelbase 7.52ft in Turning Radius Outside Tires 11ft in Weight 10361.73lb Lift F Max Lift Height 18.84ft in G Max Forward Reach 11.26ft in Lift Capacity At Max - Height 4400.43lb Max Lift Capacity 5500.54lb Max Load At Max Height 4400.43lb Max Load At Max Reach 1699.77lb Reach At Maximum Height 22.05in Lift Capacity At Max - Reach 1900.39lb Specifications Engine Power Deutz TD 2.9 L04 Tier 4f diesel 74 hp (55.4 kW) Battery 720 CCA at 0°F (-18°C) Number Of Cylinders 4 Engine Make 2349 Engine Model F4M2011 Gross Power 63hp System Voltage 12V Alternator 95amps Operational Turning Radius - Axle Outside 11ft in Operating Weight 10000.2lb Fuel Capacity 15.8gal Hydraulic System Fluid Capacity 31.8gal Drawbar Pull 10250lb Tire Size 12 x 16.5 in, 10 ply Transmission Transmission Type Hydrostatic Max Speed - Forward 15mph Hydraulic Auxiliary Hydraulic Flow 17gal/min Auxiliary Hydraulic Pressure 3918psi Pump Flow Capacity 17gal/min Relief Valve Pressure 3918psi
About this machine
The Genie GTH5519 is a used telehandler — sometimes called a reach forklift or telescopic handler — offered for sale in Texas, USA, at $59,000. Telehandlers are versatile lifting machines used across construction, agriculture, and industrial sites to place loads at height and reach, combining the function of a forklift with an extendable boom that allows materials to be positioned well beyond the machine's footprint. Genie is a well-established manufacturer of aerial work platforms and lifting equipment, serving construction, industrial, and rental markets worldwide.
This 2022 machine is powered by a Deutz TD 2.9 L04 Tier 4 Final diesel engine producing 74 horsepower (55.4 kW) from four cylinders, with a gross power rating of 63 hp. The engine is supported by a 12-volt electrical system, a 95-amp alternator, and a 720 CCA battery rated at 0°F (−18°C). A hydrostatic transmission drives the machine to a maximum forward speed of 15 mph, and a drawbar pull of 10,250 lb gives it strong traction capability on site.
The lifting specifications are central to what this machine offers. Maximum lift height reaches 18.84 feet, with a maximum forward reach of 11.26 feet. Maximum lift capacity is 5,500.54 lb, while capacity at maximum lift height is 4,400.43 lb. At maximum reach, the rated load is 1,699.77 lb, and lift capacity at maximum reach is 1,900.39 lb. The reach available at maximum height is 22.05 inches.
The machine has an operating weight of 10,000.2 lb and a gross weight of 10,361.73 lb. Its compact dimensions make it practical for confined job sites: length to fork face is 13.13 feet, width over tires is 5.91 feet, and overall height is 6.5 feet, with a wheelbase of 7.52 feet and a ground clearance of 1.19 feet. The outside turning radius over the tires is 11 feet. Tires are 12 × 16.5 inches, 10-ply.
The hydraulic system delivers an auxiliary flow of 17 gallons per minute at a relief valve pressure of 3,918 psi, with a pump flow capacity also rated at 17 gallons per minute. Total hydraulic fluid capacity is 31.8 gallons. The fuel tank holds 15.8 gallons. Financing and delivery are available on this listing.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
