2016 - Genie GTH636 Telehandler()
- Listing No
- 210867
- Year
- 2016
- Manufacturer
- Genie
- Model
- GTH636
- Condition
- Used
- Location
- USA
- Price
- $52,500
- Description
-
All listed inventory is in stock and ready for immediate purchase. Financing and delivery is available on all inventory purchases. Dimensions A Length To Fork Face 17.85ft in E Ground Clearance 1.25ft in B Width Over Tires 7.91ft in C Overall Height 7.85ft in D Wheelbase 10.93ft in Turning Radius Outside Tires 14.41ft in Weight 17599.51lb Lift F Max Lift Height 36ft in G Max Forward Reach 21ft in Lift Capacity At Max - Height 5000.09lb Max Load At Max Height 6000.99lb Max Load At Max Reach 1999.6lb Reach At Maximum Height 22.05in Lift Capacity At Max - Reach 1499.15lb Specifications Engine Power Deutz TD 2.9 L4 turbo charged diesel Emission Tier Level Tier 4f Battery 1000 CCA at 0°F (-18°C) Engine Make 2351 Engine Model 1104C-44T Gross Power 74hp System Voltage 12V Alternator 95amps Aspiration Turbocharged Operational Drive Speed 18mph Turning Radius - Axle Outside 13.4ft in Operating Weight 20999.1lb Fuel Capacity 30.2gal Hydraulic System Fluid Capacity 50gal Drawbar Pull 19200lb Tire Size 13 x 28 in, 12 ply Transmission Transmission Type Powershift Number Of Forward Gears 3 Number Of Reverse Gears 3 Max Speed - Forward 18.1mph Hydraulic Auxiliary Hydraulic Pressure 3000psi Auxiliary Hydraulic Flow 15gal/min Pump Type Variable displacement Pump Flow Capacity 6.9gal/min Relief Valve Pressure 2800psi Boom Boom Up 10sec Boom Extend 11sec Boom Retract 9sec Boom Down 8sec
About this machine
The Genie GTH636 is a used telehandler — sometimes referred to as a telescopic handler or reach forklift — a versatile lifting machine used across construction, agriculture, and industrial job sites to place, lift, and move materials at height and over distance. Genie is a well-established manufacturer of aerial work platforms and material-handling equipment, widely recognised across the construction and rental industries worldwide.
This 2016 machine is powered by a Deutz TD 2.9 L4 turbocharged diesel engine producing 74 gross horsepower, compliant with Tier 4 Final emissions standards. The 12-volt electrical system is supported by a 95-amp alternator and a 1,000 CCA battery rated at 0°F. The engine drives a three-speed powershift transmission with three forward and three reverse gears, delivering a maximum forward speed of 18.1 mph and a drawbar pull of 19,200 lb. Fuel capacity stands at 30.2 gallons.
On the lift side, the boom reaches a maximum lift height of 36 feet with a maximum forward reach of 21 feet. Lift capacity at maximum height is 5,000 lb, while the rated load at maximum reach is 2,000 lb. The machine's hydraulic system operates at an auxiliary pressure of 3,000 psi with a flow rate of 15 gallons per minute from a variable-displacement pump. Boom cycle times are efficient: extension takes 11 seconds, retraction 9 seconds, raising 10 seconds, and lowering 8 seconds.
The telehandler rides on 13 x 28 in, 12-ply tires with a ground clearance of 1.25 feet and a wheelbase of 10.93 feet. Outside turning radius over the tires is 14.41 feet. Overall dimensions are 17.85 feet in length to the fork face, 7.91 feet in width, and 7.85 feet in height. Operating weight is approximately 21,000 lb. The hydraulic system holds 50 gallons of fluid, and the system relief valve is set at 2,800 psi.
This unit is located in Texas, USA, is priced at $52,500, and financing and delivery are available.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
