2015 - Genie GTH844 Telehandler()
- Listing No
- 210959
- Year
- 2015
- Manufacturer
- Genie
- Model
- GTH844
- Condition
- Used
- Location
- USA
- Price
- $70,000
- Description
-
All listed inventory is in stock and ready for immediate purchase. Financing and delivery is available on all inventory purchases. Dimensions A Length To Fork Face 20.25ft in E Ground Clearance 1.42ft in B Width Over Tires 8.14ft in C Overall Height 7.85ft in D Wheelbase 11.32ft in Turning Radius Outside Tires 14.77ft in Weight 22599.59lb Lift F Max Lift Height 43.84ft in G Max Forward Reach 28.19ft in Lift Capacity At Max - Height 6000.99lb Max Lift Capacity 8000.58lb Max Load At Max Height 6000.99lb Max Load At Max Reach 1999.6lb Reach At Maximum Height 25.2in Lift Capacity At Max - Reach 1999.6lb Specifications Engine Power Deutz 3.6TCD turbo charged diesel Emission Tier Level Tier 4f Battery 1000 CCA at 0°F (-18°C) Engine Make 2351 Engine Model 1104C-44T Gross Power 74hp System Voltage 12V Aspiration Turbocharged Operational Drive Speed 15mph Operating Weight 22500.4lb Fuel Capacity 32gal Hydraulic System Fluid Capacity 55000.7gal Drawbar Pull 20999.1lb Tire Size 13 x 24 in, 12 ply Transmission Transmission Type Powershift Number Of Forward Gears 3 Number Of Reverse Gears 3 Max Speed - Forward 17.1mph Hydraulic Auxiliary Hydraulic Pressure 3000psi Auxiliary Hydraulic Flow 15gal/min Pump Type variable displacement Pump Flow Capacity 6.9gal/min Relief Valve Pressure 3000psi Boom Boom Extend 10sec Boom Up 13sec Boom Retract 14sec Boom Down 9sec
About this machine
The Genie GTH844 is a used telehandler — sometimes called a reach forklift or telescopic handler — available from stock in Texas, USA, priced at $70,000. Telehandlers combine the lifting capacity of a forklift with an extendable boom arm, making them essential on construction sites, in agriculture, and across industrial settings where materials must be placed or retrieved at height and reach simultaneously. Genie is a well-established manufacturer of aerial work platforms and material-handling equipment, serving construction, industrial, and infrastructure markets worldwide.
This 2015 machine has an operating weight of approximately 22,500 lb and a maximum lift capacity of 8,000 lb. At maximum lift height, the rated capacity is 6,001 lb, and at maximum forward reach the capacity reduces to 2,000 lb — figures that reflect the standard trade-off between height and reach on a telescopic boom machine. The boom extends to a maximum lift height of 43.84 ft, with a maximum forward reach of 28.19 ft and a reach at maximum height of 25.2 in.
Power comes from a Deutz 3.6TCD turbocharged diesel engine producing 74 gross horsepower, running on a 12-volt electrical system with a 1,000 CCA battery. The engine meets Tier 4 Final emissions standards. A fuel capacity of 32 gallons supports extended operation, and the hydraulic system uses a variable-displacement pump delivering 15 gal/min of auxiliary flow at a relief pressure of 3,000 psi.
Drive is handled by a powershift transmission with three forward and three reverse gears, giving a maximum forward speed of 17.1 mph and a general drive speed rating of 15 mph. Drawbar pull is rated at 20,999 lb. The machine rolls on 13 × 24 in, 12-ply tires with a ground clearance of 1.42 ft and a wheelbase of 11.32 ft. Overall dimensions are 20.25 ft in length to fork face, 8.14 ft wide over the tires, and 7.85 ft in overall height, with an outside turning radius of 14.77 ft.
Boom cycle times are documented: boom up takes 13 seconds, boom down 9 seconds, boom extend 10 seconds, and boom retract 14 seconds. Financing and delivery are available on this unit.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
