2020 - Yawa DS106 Die Cutter
()- Listing No
- 907271
- Year
- 2020
- Manufacturer
- Yawa
- Model
- DS106
- Condition
- Used
- Location
- Bulgaria
- Price
- POA
- Description
-
Description Age: 2020 Max.Size: 106 x 76 cm (41 x 29 inch) Impress.Count: mioExtras:Description: Technical specifications: , Sheet , Max.sheet size:1060×760mm, Min.sheet size:400×350mm, Stockrange: , Paper from 90gsm, Paperboard:0.2-1.5mm, Corrugatedboard: ≤4mm (E,B FFLUTE), Min.gripper edge:9mm, Die-cutting , Max.die-cutting size:1060×746mm, Innerchase size:1124×788mm, Max.pressure:260tons, Maxspeed:6500sph, Steelrules height:23.8mm, Main motor capacity:15kw, Total power capacity:28kw, Feeder pile height:1400mm, Deliverypile height:1200mm, Net weight:22,000kg, Non-stop sheet loading, Micro adjustable side lays with pull/push in one, 1mm thin plate, Two independent lays with photoelectric detection, Full technical specification - on request Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase
About this machine
The Yawa DS106 is a used die cutter — also known as a flatbed die cutter or platen die cutter — a machine used to cut, crease, and blank sheet materials such as paper, paperboard, and corrugated board into precise shapes for packaging and print finishing applications.
This 2020 machine handles a maximum sheet size of 1,060 × 760 mm and a minimum sheet size of 400 × 350 mm, making it well suited to a broad range of sheet formats. On the material side, it accepts paper from 90 gsm, paperboard up to 1.5 mm thick, and corrugated board up to 4 mm (E and B flute grades). The minimum gripper edge is 9 mm. The maximum die-cutting area measures 1,060 × 746 mm, with an inner chase size of 1,124 × 788 mm, and the machine uses steel rules with a height of 23.8 mm.
Production speed reaches a maximum of 6,500 sheets per hour, and the die-cutting unit develops a maximum pressure of 260 tons — figures that position this machine for medium-to-high volume production environments. The main motor is rated at 15 kW, with a total installed power capacity of 28 kW. The machine weighs 22,000 kg net.
Feeding and delivery are designed for operational efficiency. The feeder pile height is 1,400 mm and the delivery pile height is 1,200 mm. Non-stop sheet loading is included, allowing pile changes without halting production. Sheet registration is handled by micro-adjustable side lays with combined push/pull action, supported by two independent lays with photoelectric detection. A 1 mm thin plate is also noted as part of the configuration.
The machine is located in Bulgaria and is available as used. Full technical documentation is available on request from the seller.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
