2005 - Bäuerle Baeuer Flexo-Folder Gluer
()- Listing No
- 1092736
- Year
- 2005
- Manufacturer
- Bäuerle
- Model
- Mathias Baeuer
- Condition
- Used
- Location
- Germany
- Price
- POA
- Description
-
Marke: Mathias Baeuerle Computer control with automatic adjustment (rulers and pockets of the folding units can be adjusted automatically) Flat pile feeder FL Format: min. 10x12cm max. 52×85 cm Paper weight 40-250gr/m² 1.Work 4 pockets 52 cm with downstream cutterhead Surplus table 2.work 4 pockets 52cm with downstream cutterhead Shed display Circulation and preset counters Double sheet control Sound insulation hoods
About this machine
This Bäuerle Baeuerle Flexo-Folder Gluer is a used flexo-folder gluer — sometimes referred to as a folder-gluer or box-making machine — built in 2005 and currently located in Germany. Flexo-folder gluers are specialist finishing machines used in the corrugated and folding carton industry to print, fold, and glue flat blanks into finished boxes in a single, continuous pass. Bäuerle, trading also as Mathias Bäuerle, is a German manufacturer with a long history of producing precision folding and finishing equipment for the print and packaging industries.
According to the seller's information, this machine is equipped with computer control and automatic adjustment, meaning the rulers and pockets of the folding units can be set and corrected automatically rather than by hand — a significant productivity and repeatability advantage when changing between jobs. The feeder is a flat pile feeder (designated FL), which feeds sheets individually from a flat stack into the machine.
The machine handles a format range from a minimum of 10 × 12 cm up to a maximum of 52 × 85 cm, giving it considerable versatility across small and large box sizes. It accepts paper and board weights between 40 and 250 g/m², covering lightweight papers through to heavier corrugated or solid board grades.
The configuration comprises two work stations. The first work station features four pockets with a 52 cm working width and a downstream cutterhead, along with a surplus table. The second work station is similarly equipped with four pockets at 52 cm with a downstream cutterhead, and additionally includes a shed display. Both stations together provide a total of eight folding pockets, enabling complex multi-break fold patterns in a single pass.
Further equipment included with the machine comprises circulation and preset counters, a double sheet control system to detect and reject overlapping sheets before they enter the folding section, and sound insulation hoods fitted around the machine to reduce operational noise levels.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
