2019 - Demag Systec 210 580 Injection Moulding
()- Listing No
- 1151544
- Year
- 2019
- Manufacturer
- Demag
- Model
- Systec 210 580
- Condition
- Used
- Location
- Germany
- Price
- POA
- Description
-
This DEMAG Systec 210/580-840 was manufactured in 2019. It's a hydraulic injection moulding machine with a clamping force of 210 tons and a power output of 60 kW. It has been used for 31,132 operating hours. Consider the opportunity to buy this DEMAG Systec 210/580-840 hydraulic injection moulding machine. Contact us for more information. Location: DE With side ejector plate, centering diameter of fixed platen: 160 mm Min: 340 mm Max: 790 mm The dosing unit (orange part) is not included Integrated socket combination country-specific can be switched off via main switch and shutdown program 2 x Schuko 1Ph/230V/16A 2 x IECEE 3Ph/400V/16A residual current device Pneumatic 5/2 valve No. 1 on movable mold clamping plate programmable supplied via central air connection includes hoses. Inputs and outputs freely programmable 3 inputs and 3 outputs Terminal point outside the control cabinet Interface for additional nozzle heating band socket only 2-circuit core puller via switching valve on movable mold clamping plate Q-independent (programmable) With pilot-operated check valves to prevent core creep Mold connection dimensions E (similar to Euromap March 96) Centering diameter of movable platen Mold installation height increased by 100.0 mm
About this machine
This Demag Systec 210 580 is a used hydraulic injection moulding machine — sometimes referred to as an injection moulding press — manufactured in 2019 and located in Germany. Injection moulding machines are used to produce plastic components by injecting molten material into a mould under pressure, and are fundamental to manufacturing across the automotive, consumer goods, packaging, and electronics industries. Demag is a well-established name in plastics processing machinery, with a long history of producing precision injection moulding equipment for industrial production environments.
The machine delivers a clamping force of 210 tons and a power output of 60 kW. It has accumulated 31,132 operating hours of use. The mould installation height range runs from a minimum of 340 mm to a maximum of 790 mm, with the installation height increased by a further 100 mm. The centering diameter of the fixed platen is 160 mm, and mold connection dimensions follow the E specification, similar to Euromap March 96 standard. A centering diameter is also present on the movable platen.
The machine is equipped with a side ejector plate and a 2-circuit core puller mounted via a switching valve on the movable mold clamping plate. The core puller is Q-independent and fully programmable, and pilot-operated check valves are fitted to prevent core creep. A pneumatic 5/2 valve (No. 1) is located on the movable mold clamping plate, is programmable, and is supplied via the central air connection, complete with hoses; its inputs and outputs are freely programmable, with 3 inputs and 3 outputs, and the terminal point is positioned outside the control cabinet.
The electrical socket combination is integrated and country-specific, switchable via the main switch and shutdown program. It includes two Schuko single-phase 230 V/16 A sockets and two IECEE three-phase 400 V/16 A sockets with residual current device protection. An interface for an additional nozzle heating band is present, provided as a socket connection only. It should be noted that the dosing unit — the orange component — is not included in this listing.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
