1998 - Eurovent MPR 502 Dust Collector()
- Listing No
- 931213
- Year
- 1998
- Manufacturer
- Eurovent
- Model
- MPR 502
- Condition
- Used
- Location
- Germany
- Price
- POA
- Description
-
Radial fan, dust extraction fan, fan, extraction, dust blower, blower, exhaust fan -Manufacturer: Eurovent, dust extraction fan radial fan type MPR 502 Dko Uperp Ii Uongnvog -Motor: AEG 5.5 kW 2860 rpm -Volume flow: 3000 m³/h -Pressure: 3900 Pa -Connection: Inlet Ø 305 mm -Connection: Output 220 x 160 mm -Base plate: 415 x 400 mm -Dimensions: 755/750/H770 mm -Weight: 100 kg Request more information Request more information Already requested
About this machine
This Eurovent MPR 502 is a used dust collector — also commonly referred to as a dust extractor — designed to capture and remove airborne particulate matter from industrial working environments. Machines of this type are widely used in woodworking, metalworking, food processing, and other manufacturing settings where the control of airborne dust and debris is essential for both worker safety and process cleanliness. Eurovent is a manufacturer known for producing industrial ventilation and air-handling equipment, including centrifugal and radial fans used in extraction and process air systems.
This unit is built around a radial fan configuration, making it well suited to moving large volumes of air against meaningful resistance. The fan is driven by an AEG motor rated at 5.5 kW, running at 2,860 rpm. At that speed, the unit delivers a volume flow of 3,000 m³/h, with a static pressure of 3,900 Pa — a combination that reflects solid extraction capacity for demanding industrial applications.
Connectivity is straightforward: the inlet is a circular connection of Ø 305 mm, while the outlet is a rectangular port measuring 220 × 160 mm. The unit sits on a base plate of 415 × 400 mm, giving it a stable and compact footprint. Overall dimensions are 755 × 750 × 770 mm (H), and the machine weighs approximately 100 kg. The unit dates from 1998 and is offered in used condition from a location in Delaware, Germany.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
