About this machine

The Fliegl Gigant ASW 310 is a rear-discharge dump trailer manufactured by Fliegl, a leading producer of agricultural and commercial trailers. Dump trailers of this type are used for bulk commodity transport and controlled discharge of grain, feed, aggregates, and other loose materials across farms, quarries, and industrial operations.

This unit is configured as a tridem (three-axle) hydraulic dump trailer with a 55-cubic-metre capacity. The chassis measures 9300 mm × 2380 mm and is rated to a maximum authorised gross weight of 33 tonnes. The entire rear section, comprising both side walls and hydraulic discharge gate, stands 2000 mm high, with an overall superstructure length of 10100 mm. The walls are galvanised for corrosion resistance, and the unit is fitted with a front wall extension and 300 mm aluminium side panelling.

The suspension system uses full hydraulic springing across all axles for enhanced ride comfort and load control. The three-point steering configuration features hydraulic forced-steering on both front and rear axles with the centre axle fixed. Braking is handled by a dual-circuit pneumatic system with automatic load-sensing brakes (ALB) and 410 × 180 mm brake drums supplied by BPW. Tyres are 710/50 R 30.5 specification across all positions. The trailer is rated to 40 km/h and carries EU type approval with COC documentation.

The discharge mechanism comprises a hydraulic floor conveyor fitted with running polyurethane seals for tight grain sealing, paired with a large-volume hydraulic rear gate measuring 800 mm deep and a 420 × 250 mm grain chute. A hydraulic side-guard deflector can be folded up clear of the wheels. Lighting is LED 12-volt with a seven-pin connector. Connection to the tractor hydraulic system is made via a ball coupling (K80, Ø 80 mm) with fall-back support.

Equipment includes a power-take-off (PTO) shaft drive with clutch for mechanical operation, side- and rear-corner LED outline lights, plastic mudguards and rear apron, front-mounted climb ladder, 40 km/h type approval including side underrun protection and marker lights, and a Protect specification package. The unit may be operated using the tractor's control unit. The trailer is presented in good used condition and is located in Germany.

This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
