2019 - KPI-JCI FT2650 Quarry Crusher()
- Listing No
- 271792
- Year
- 2019
- Manufacturer
- KPI-JCI
- Model
- FT2650
- Condition
- Used
- Location
- USA
- Price
- $550,000
- Description
-
• VIBRATING GRIZZLY FEEDER –50” X 15’ Vibrating Pan Feeder –6.5 Cubic yard Hopper –5’ Step deck grizzly bars 2-1/2 spacing –Three position flop gate •JAW CRUSHER –2650 Vanguard Jaw –Hydraulically adjustable –Hydraulically driven and reversible • CHASSIS –Sculpted boxed frame design –600mm tracks with dual drive –Track width 10’9”/3.276m –Balanced for zero cribbing –115 gal/435 L Oil Reservoir •UNDERCRUSHER CONVEYOR –48” x 38’ Under crusher conveyor –Impact bed with 330 3ply belting –Easily removed for maintenance • POWER UNIT –Cat C9.3 300hp/224 kw Tier IV –Cat C9 300hp/224 kw Tier III (International) –170gal/643.5L fuel tank –Fuel consumption 8-12 Gal/Hr
About this machine
The KPI-JCI FT2650 Quarry Crusher is a used tracked jaw crusher — sometimes referred to as a mobile crushing plant — designed for primary reduction of rock, stone, and other hard materials in quarrying and aggregate production operations. KPI-JCI, a brand of Astec Industries, manufactures heavy crushing, screening, and conveying equipment for the aggregate, mining, and construction industries and is well regarded for its Vanguard series jaw crushers.
This 2019 machine is built around a 2650 Vanguard jaw crusher that is both hydraulically adjustable and hydraulically driven, with a reversible drive that helps clear blockages and reduce downtime. Feed material is introduced through a 50-inch by 15-foot vibrating pan feeder mounted beneath a 6.5-cubic-yard hopper. A five-foot step-deck grizzly section with 2½-inch bar spacing pre-screens fines ahead of the jaw, and a three-position flop gate gives the operator control over material flow routing.
The chassis uses a sculpted boxed frame design and rides on 600 mm dual-drive tracks with an overall track width of 10 feet 9 inches (3.276 m). The machine is described as balanced for zero cribbing, meaning it can be set up on level ground without additional support blocking. An oil reservoir of 115 gallons (435 L) is integrated into the frame. Crushed material exits via a 48-inch by 38-foot undercrusher conveyor fitted with an impact bed and 330 three-ply belting; the conveyor is designed for easy removal to simplify maintenance access.
Power is provided by a Caterpillar C9.3 engine rated at 300 hp (224 kW) to Tier IV emissions standards for the North American market, with a Tier III-compliant Cat C9 of the same output available for international configurations. The onboard fuel tank holds 170 gallons (643.5 L), and fuel consumption is rated at 8 to 12 gallons per hour depending on operating conditions. This machine is located in Nevada, USA, and is offered at $550,000.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
