2023 - Manitou MT 730H Telehandler()
- Listing No
- 764415
- Year
- 2023
- Manufacturer
- Manitou
- Model
- MT 730H
- Condition
- Used
- Location
- Germany
- Price
- POA
- Description
-
Internal Stock Number : g06042Construction Power Type : 7500002Max lift power : 3,000 kgLift height : 6.90 mOther information : - Max. Tragkraft 3000 kg- Max. Hubhöhe 6.90 m- Maximale seitliche Reichweite 4 m- Kippwinkel 11 ° - Schüttwinkel 116 ° - Wenderadius (über Räder) 3.33 m - Getriebetyp Hydrostatisch - Standard Bereifung ALLIANCE 380/75 R20 148A8 A580- Anzahl der Gänge (vorwärts / rückwärts) 2 / 2 - Max. travel speed 24.90 km/h - Festellbremse Hydraulik - Lenkräder (vorne / hinten) 4 / 4 - Sicherheit Zulassung der Kabine Kabine ROPS - FOPS Stufe 2- Heben 9.42 s - Senken 7.53 s - Teleskop ausfahren 7.43 s - Teleskop Einfahren 9.36 s - Ankippen 3.21 s - Auskippen 2.15 s - Motornorm Stage V- Motor Modell V3307-CR-TE5B- Anzahl der Zylinder / Tragfähigkeit der Zylinder 4 - 3331 cm- Nennleistung Verbrennungsmotor - Leistung (kW) 55.92 kW / 54.60 kW- Max. Drehmoment / Motordrehzahl 265 Nm ... 1400 rpm- Zugkraft 3860 daN- Anzahl der Gänge (vorwärts / rückwärts) 2 / 2 - Max. travel speed 24.90 km/h - Festellbremse Hydraulik - Pumpenart Zahnradpumpe - Hydraulikfördermenge / Hydraulikdruck 88 l/min / 245 bar- Motoröl 11 l - Hydrauliköl 115 l - Fassungsvermögen des Kraftstofftanks 90 l - Geräuschpegel im Fahrerstand (LpA) 74 dB- Umgebungsgeräusch (LwA) 103 dB - Schwingungsbelastung Hand/Arm < 2.50 m/s² - Lenkräder (vorne / hinten) 4 / 4
About this machine
This Manitou MT 730H is a telehandler — also commonly referred to as a telescopic handler — a versatile lifting machine used across construction, agriculture, and industrial sites to raise, place, and transport heavy loads at height and reach. Manitou is a well-established French manufacturer with decades of experience building material handling equipment, including telehandlers, rough-terrain forklifts, and aerial work platforms, serving sectors from building and civil engineering to agriculture and warehousing. This example is a 2023 used machine located in Germany.
At the heart of its specification is a maximum lift capacity of 3,000 kg and a maximum lift height of 6.90 m, making it well suited to loading and placing palletised materials, prefabricated elements, and bulk containers at height. The maximum lateral reach extends to 4 m, and the machine offers a tipping angle of 11° and a dump angle of 116°, giving operators flexibility when loading and discharging attachments. The turning radius over the wheels is 3.33 m, reflecting the compact dimensions needed for tighter site conditions. Steering is four-wheel on both axles.
Power comes from a Kubota V3307-CR-TE5B four-cylinder diesel engine displacing 3,331 cc and meeting the current EU Stage V emissions standard. Rated output is 55.92 kW, with a peak torque of 265 Nm at 1,400 rpm. Drive is through a hydrostatic transmission with two forward and two reverse gears, giving a maximum travel speed of 24.90 km/h. Tractive effort is rated at 3,860 daN. The parking brake is hydraulically operated.
The hydraulic system uses a gear pump delivering 88 litres per minute at a working pressure of 245 bar. Cycle times are fully documented: boom raise takes 9.42 seconds, lower 7.53 seconds, telescope extension 7.43 seconds and retraction 9.36 seconds, crowd-in 3.21 seconds, and dump 2.15 seconds. The hydraulic oil capacity is 115 litres, engine oil capacity is 11 litres, and the fuel tank holds 90 litres. Standard tyres are Alliance 380/75 R20 148A8 A580.
The operator's cab carries ROPS and FOPS Level 2 certification, meeting current safety standards for rollover and falling-object protection. In-cab noise level is measured at 74 dB (LpA), with an environmental sound power level of 103 dB (LwA). Hand-arm vibration exposure is rated at below 2.50 m/s², in line with operator comfort and regulatory requirements. The machine is listed under internal stock number g06042.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
