MAS VR 4A – MK 4 – X 1000 MM Drilling Machine
()- Listing No
- 955187
- Year
- Manufacturer
- MAS
- Model
- VR 4A - MK
- Condition
- Used
- Location
- Belgium
- Price
- POA
- Description
-
max distance between table and spindle: 1300 mm Admission in drilling-spindle (morse): Cone 4 Max drilling capacity: 50/60 mm Longitudinal travel drilling-head (X-axis): 945 mm Height-travel arm (Y-axis): 710 mm Min dist. round column--drillingsp (X-axis): 310 mm Max dist.round column -- drillingspindle: 1255 mm Dia spindle: 40 mm Max drilling-depth: 310 mm Speeds: 40 > 2000 rpm Power on the spindle: 3 kW Weight: 910 mm ACCESSORIES: 2860 mm Cooling system: 2,55 ton
About this machine
This MAS VR 4A - MK 4 - X 1000 MM is a used drilling machine — sometimes referred to as a radial drill or radial arm drill — designed for precision boring and drilling operations across a wide range of workpiece sizes. MAS is a well-established Czech machine tool manufacturer with a long history of producing industrial metal-cutting and machining equipment for the engineering and manufacturing sectors.
The machine is equipped with a Morse taper cone 4 spindle seat, with a spindle diameter of 40 mm, and offers a maximum drilling capacity of 50 to 60 mm. The spindle speed range runs from 40 to 2,000 rpm, providing the flexibility to handle both slow, heavy-duty drilling and faster, smaller-diameter work. Spindle power is rated at 3 kW.
In terms of reach and travel, the drilling head travels 945 mm along the X-axis (longitudinal travel), while the arm can be raised or lowered through a height travel of 710 mm on the Y-axis. The minimum distance from the round column to the drilling spindle is 310 mm, and the maximum distance extends to 1,255 mm, giving considerable reach across large workpieces. Maximum drilling depth is 310 mm, and the maximum distance between the table and spindle is 1,300 mm. The machine is also fitted with a cooling system. This unit is located in Belgium and is offered in used condition.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
