2002 - MBO K 800-FP120 Folding Machine()
- Listing No
- 907858
- Year
- 2002
- Manufacturer
- MBO
- Model
- K 800-FP120
- Condition
- Used
- Location
- France
- Price
- POA
- Description
-
Description MBO K800S4 KTLYear: 2002- feeding mode: pallet- type: k 800-fp120- pockets: 4x- pocket type: combi folding plates- pocket configuration: motorized automatic- cross folding unit with electronic knives 2x- 1x side pocket- noise protection hood- vacuum pump- max. format: 780 x 1200 mm- max. mechanical speed: 210 m / min.-- palamides 703 delta year 2006- width 76 cm- mobile stacking system for markfree delivery- group output max. 3 joggers- pressing station- max. width 760 mm - 1- max. width 235 mm - 3- max. 600 packages / hour- motorized output with roller table Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase
About this machine
This MBO K 800-FP120 is a used folding machine — sometimes referred to as a paper folder or sheet folding machine — built in 2002 and currently located in France. Folding machines of this type are core finishing equipment in commercial print and bindery operations, used to fold sheets into brochures, leaflets, booklet sections, and a wide range of other folded products. MBO is a well-established German manufacturer with a long-standing reputation in the graphic arts and print-finishing industry, producing high-performance folding and finishing systems for professional print environments worldwide.
The machine is configured as a pallet-fed system, accommodating large-format sheets up to 780 × 1,200 mm. It runs at a maximum mechanical speed of 210 metres per minute, placing it in the higher-throughput bracket of commercial folding equipment. The folding unit features four pockets with combi folding plates — a combination format that allows both buckle and knife folding sequences — and the pocket configuration is motorised and automatic. In addition to the main fold sequence, the machine is equipped with two electronic cross-folding units and one side pocket, extending the range of fold patterns it can produce. A noise protection hood and a vacuum pump are included as part of the setup.
Accompanying this machine is a Palamides 703 Delta delivery and stacking system, manufactured in 2006. This unit is 76 cm wide and incorporates a mobile stacking system designed for mark-free delivery of folded products — an important feature when handling printed sheets that must reach the next process stage without surface damage. The output system includes a group output with a maximum of three joggers and a pressing station. The delivery accommodates a maximum width of 760 mm for one delivery channel and up to 235 mm for three channels, with a rated output of up to 600 packages per hour. The output section is motorised and fitted with a roller table.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
