2007 - Muller BRAVO-PLUS AMR Saddle Stitcher
()- Listing No
- 1021934
- Year
- 2007
- Manufacturer
- Muller
- Model
- BRAVO-PLUS AMR
- Condition
- Used
- Location
- Germany
- Price
- POA
- Description
-
Sammelhefter / Saddle Stitcher Müller Martini Bravo Plus AmrysYear 2007 - SN. MMZO 1 306 445 – Working hours 7.100Std./h PLC Steuerung mit Display - Geschwindigkeit max. 14.000 cyc./h. Size (untrimmed) max. 320 x 480mm - (trimmed) min. 105 x 148mm - Product thickness max. 5mm 6 Feeder Type 0370.0458 - SN. MMZO 1 306 445 Umschlaganleger / Cover Feeder Type 1529.0416 - SN. NN35997/ZO1306447 Doppelbogen/Dickenkontrolle / Semko Thickness Control Type 0333.0435 Heftstation / Stitching unit Bravo Plus Typ 0380.0450 - SN. MMZO 1 306 445 Dreischneider / Three Knife Trimmer 0449.0435 - SN. MMZ0 1 306 445 Bandauslage / Band Delivery Müller Martini 1564.0400 Manuals all included
About this machine
This Muller Bravo Plus AMR is a saddle stitcher — a type of machine used in commercial printing and bookbinding to collate, stitch, and trim folded signatures into finished saddle-bound booklets, catalogues, and brochures. Sometimes referred to as a saddle binder, this class of equipment is a core production tool in short- to medium-run periodical and commercial print finishing. Müller Martini is a well-established Swiss manufacturer of print finishing and bookbinding systems, supplying inline and standalone solutions to commercial printers, publishers, and trade binderies worldwide.
This particular machine was built in 2007 and carries serial number MMZO . It has logged 7,100 working hours and is located in Germany. The line is controlled by a PLC system with an operator display and is rated to a maximum output speed of 14,000 cycles per hour, placing it firmly in the high-productivity segment for saddle-stitching lines.
The machine handles an untrimmed product size up to 320 × 480 mm and, after trimming, a minimum finished size of 105 × 148 mm, giving it coverage from small digest formats up to larger catalogue sizes. Maximum product thickness is 5 mm. The gathering section comprises six pocket feeders, each of type , allowing up to six signatures to be collated per cycle. A dedicated cover feeder — type , serial number NN35997/ZO1306447 — feeds the outer cover separately, as is standard for saddle-stitching lines of this configuration.
Quality control is handled by a Semko double-sheet and thickness detection unit, type , which monitors the stream for misfeeds and out-of-tolerance products. Stitching is performed by a Bravo Plus stitching unit, type . Finished products pass through a three-knife trimmer, type , which squares and trims the head, foot, and face of each booklet in a single pass. Delivery is via a Müller Martini band delivery unit, type , which stacks and conveys completed products off the line. All original manuals are included with the machine.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
