2005 - Palamides Delta 705 Folding Machine()
- Listing No
- 1020551
- Year
- 2005
- Manufacturer
- Palamides
- Model
- Delta 705
- Condition
- Used
- Location
- Germany
- Price
- POA
- Description
-
Working width 700 mm with 5-fold banding Format range max. 760 x 305mm min. 110 x 95 mm Bandwidth 30 mm automatic format recognition and waste sheet detection Pressing station with pre-pressing and main pressing with main pressing roller Package pressing Vibrating station autom. Format setting Large format display Different operating modes stream feeder or single sheet feeder quick adjustment counter bar bundling Output 600 packages per hour Package height: min. 20 mm Package height: max. 150 mm Capacity: 600 packages/h per use Speed: up to 60,000 pcs./h Speed: 15-205 m/min Electrical connection: 6KW Inlet height: 410mm – 1000mm
About this machine
The Palamides Delta 705 is a used folding machine — sometimes referred to as a folder-gluer or sheet folding machine in the print finishing trade — currently located in Germany and dating from 2005. Folding machines of this type are used in the printing and packaging industry to fold, press, and bundle printed sheets or signatures into neat, uniform packages ready for further processing or despatch. Palamides is a well-regarded German manufacturer specialising in paper handling and finishing equipment, producing systems for stacking, bundling, and folding that serve commercial printers, bookbinders, and packaging producers.
This machine accepts a working width of 700 mm and handles a broad format range, from a minimum sheet size of 110 × 95 mm up to a maximum of 760 × 305 mm. The bandwidth is 30 mm, and the inlet height is adjustable between 410 mm and 1,000 mm, accommodating a variety of production line configurations. Electrical connection is rated at 6 kW.
The Delta 705 is equipped with automatic format recognition and automatic waste sheet detection, reducing manual intervention during production runs. Format setting is also automatic, and the machine features quick adjustment capability alongside a large-format display for operator monitoring. A counter is included as standard. The unit can be fed via either a stream feeder or a single sheet feeder, offering flexibility in how it is integrated into an existing workflow.
The pressing station incorporates both a pre-pressing stage and a main pressing stage, including a main pressing roller, as well as a dedicated package pressing function. A vibrating station is fitted to ensure neat, aligned stacking of output. The machine operates in multiple configurable operating modes and includes bar bundling for securing completed packages.
Output capacity is rated at 600 packages per hour, with package height ranging from a minimum of 20 mm to a maximum of 150 mm. Sheet processing speed reaches up to 60,000 pieces per hour, with a belt speed range of 15 to 205 metres per minute. The five-fold banding configuration rounds out the specification of this well-equipped, production-grade folding machine.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
