2010 - Sandretto KN 35000 Injection Moulding
()- Listing No
- 1152400
- Year
- 2010
- Manufacturer
- Sandretto
- Model
- KN 35000
- Condition
- Used
- Location
- Portugal
- Price
- POA
- Description
-
Injection machine SANDRETTO HES 3500 (with MASTER MATTIC RB 500CN robot). 1.2 TECHNICAL DATA TYPE MEGA H ES MODEL KN 35000 EUROMAP CLASSIFICATION 54250 Control Panel SEF 2000 Thread diameter mm 200 L/D Ratio L/D 20 Theoretical injection volume cm3 36110-18000 Injection ratio cm3/s 3147 Maximum injection pressure Bar 1670 Plasticizing Capacity (HDPE) g/s 280 Plasticizing Speed RPM 0-110 Simultaneous Plasticizing Speed RPM 0-55 Maximum torque Nm 43000 Heating zones + nozzle n 6 + 1 Unit injection stroke mm 1600 Total heating power kW 174 Closing force kN 35000 Mold height min/max mm 1000÷2200 Opening stroke mm 2300 Plate dimensions (Horizontal x Vertical) mm 3360x3060 Passage between columns (Horizontal x Vertical) mm 2230x1930 Column diameter mm 470 Extraction force kN 550 Extraction stroke mm 600 No load cycle (Euromap) s 3.6 Oil tank capacity l 8000 Hydraulic system pressure bar 195 Electric motor power kW 528 (4x132) Total installed power kW 721 Machine dimensions (L x H x W) mm 19135 4440 5550 Machine Weight (closing – injection) ton 276 - 70 Fixed maximum weight 35tns PMM Maximum mobile weight 44,400tns PMM Total mold maximum 66,600tns PMM Show the whole comment
About this machine
This Sandretto KN 35000 is a large-format injection moulding machine — also referred to as an injection moulding press — built for the high-volume production of plastic components. Injection moulding machines of this class are used across a wide range of industries, including automotive, packaging, consumer goods, and industrial components, where molten plastic is injected under high pressure into a closed mould to produce parts with consistent geometry and surface quality. Sandretto is a well-established Italian manufacturer with a long history of producing industrial injection moulding equipment, and this machine was built in 2010 and is offered used from Portugal.
At the heart of the machine's capability is its closing force of 35,000 kN, which places it firmly in the heavy-duty large-tonnage category. The platens measure 3,360 mm × 3,060 mm, with a daylight passage between the tie bars of 2,230 mm × 2,930 mm and a tie-bar diameter of 470 mm. Mould height can be accommodated in the range of 1,000 mm to 2,200 mm, and the opening stroke extends to 2,300 mm. The machine is equipped with an ejection system delivering 550 kN of extraction force over a stroke of 600 mm. Mould weight capacity is substantial: up to 35 tonnes for fixed elements, 44,400 kg for mobile elements, and 66,600 kg total mould weight.
The injection unit is equally substantial. The screw diameter is 200 mm with an L/D ratio of 20, and the theoretical injection volume ranges from 18,000 to 36,110 cm³. The injection rate reaches 3,147 cm³/s, and maximum injection pressure is 1,670 bar. Plasticising capacity for HDPE is rated at 280 g/s, with screw speed ranging from 0 to 110 rpm and simultaneous plasticising speed up to 55 rpm. Maximum screw torque is 43,000 Nm. The barrel features six heating zones plus a nozzle, with a total heating power of 174 kW and an injection stroke of 1,600 mm.
The hydraulic system operates at 195 bar with an oil tank capacity of 8,000 litres. The machine is powered by four electric motors totalling 528 kW (4 × 132 kW), and total installed power stands at 721 kW. The no-load cycle time per the Euromap classification 54250 standard is 3.6 seconds. The machine's overall footprint is 19,135 mm × 5,550 mm × 4,440 mm, and machine weight is approximately 276 tonnes for the closing unit and 70 tonnes for the injection unit.
The listing includes a Master Mattic RB 500CN robot and an SEF 2000 control panel. The machine is located in Portugal and is available in used condition.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
