2023 - Still 60-80 Electric Forklift()
- Listing No
- 761300
- Year
- 2023
- Manufacturer
- Still
- Model
- 60-80
- Condition
- Used
- Location
- Germany
- Price
- €137,000
- Description
-
Internal Stock Number : 5886Max lift power : 8,000 kgLoad centre : 900 mmLift height : 4,500 mmFree lift : 1,580 mm Drive height : 2,900 mmLift Mast : 4000023Truck cabin : 4000012Engine : ElectricTransport weight : 14,100 kgTransport dimension : 3380 x 2140 x 2900 mmAccessories : 3. Ventil, 4. Ventil, Heizung, Vollkabine, Außenspiegel, Rundumleuchte,Other information : - Bedienung: Sitzgerät- Tragfähigkeit/Last: 8000 kg- Lastschwerpunktabstand: 900 mm- Achslast mit Last vorn/hinten kg 21306/2124- Achslast ohne Last vorn/hinten kg 7097/8333- Spurweite vorn/hinten mm 1561/1432- Neigung Hubgerüst/Gabelträger vor/zurück α/β 5/8 °- Höhe Hubgerüst eingefahren 2710 mm- Kupplungshöhe mm 520/670- Gabelträger ISO 2328, Klasse/Typ A, B ISO IV A- Arbeitsgangbreite bei Palette 1000 x 1200 quer mm 4999- Arbeitsgangbreite bei Palette 800 x 1200 längs mm 5199- Wenderadius mm 3049- Kleinster Drehpunktabstand mm 877- Fahrgeschwindigkeit mit/ohne Last km/h 14/17 // 18/20 4- Hubgeschwindigkeit 5 mit/ohne Last m/s 0,28/0,37 // 0,36/0,48 - Senkgeschwindigkeit 5 mit/ohne Last m/s 0,53/0,42- Zugkraft mit/ohne Last N 27997/28295- max. Zugkraft mit/ohne Last N 44000- Steigfähigkeit mit/ohne Last % 15,5/22,5- Max. Steigfähigkeit mit/ohne Last % 16,0/23,0- Beschleunigungszeit (15 m) 5 mit/ohne Last s 7,9/6,8//6,9/6,1- Betriebsbremse Mechanisch/hydraulisch- Batterie nach DIN 43531/35/36 A, B, C, nein DIN 43536 A- Batteriespannung V 80- Batteriekapazität K5 Ah 1120 (-1240) // 1085- Energieverbrauch 45 VDI-Arbeitsspiel/Stunde kWh/h 17,7- Umschlagleistung 5 t/h 456 // 476- Energieverbrauch bei Umschlagleistung kWh/h 17,2 // 21,9- Arbeitsdruck für Anbaugerät bar 250- Ölstrom für Anbaugeräte l/min 60- Schalldruckpegel LpAZ (Fahrerplatz) 2 dB(A) <70- Humanschwingung: Beschleunigung nach EN 13059 m/s² <0,7- Anhängerkupplung, Art/Typ DIN 15170 Bolzen
About this machine
This Still 60-80 is an electric forklift — sometimes referred to as an electric lift truck — a type of material-handling machine used across warehousing, logistics, manufacturing, and heavy-duty industrial operations to raise, transport, and stack loads at height. Still is a well-established German manufacturer with a strong reputation in the intralogistics sector, producing electric and counterbalanced forklifts, reach trucks, and warehouse equipment for demanding commercial and industrial environments.
This 2023 machine is offered in used condition from a seller in Germany, priced at €137,000. It is a seated operator (sit-down) configuration with an 80-volt electric drivetrain and carries an impressive rated capacity of 8,000 kg at a load centre of 900 mm, placing it firmly in the heavy-duty end of the counterbalance forklift market. The transport weight of the machine itself is 14,100 kg, and its overall transport dimensions are 3,380 × 2,140 × 2,900 mm.
The mast specification is substantial: lift height reaches 4,500 mm, free lift is 1,580 mm, and the mast retracts to a closed height of 2,710 mm, making it suitable for working in environments with overhead constraints. Drive height is quoted at 2,900 mm. The fork carriage conforms to ISO 2328 Class/Type A, B, ISO IV A. Mast tilt angles are 5° forward and 8° backward. Coupling height is given as 520/670 mm.
Travel speeds are 14/17 km/h with load and 18/20 km/h without load, depending on configuration. Lift speed is 0.28/0.37 m/s laden and 0.36/0.48 m/s unladen, while lowering speed is 0.53 m/s with load and 0.42 m/s without. Drawbar pull reaches up to 44,000 N maximum, with rated tractive force of 27,997 N laden and 28,295 N unladen. The machine can negotiate gradients of up to 15.5% under load and 22.5% without, with maximum gradeability figures of 16.0% and 23.0% respectively. Acceleration over 15 metres is 7.9 seconds with load and 6.8 seconds without.
The battery system operates at 80 V with a capacity of 1,120 Ah (up to 1,240 Ah) to DIN 43536 A. Energy consumption per VDI duty cycle is 17.7 kWh/h, and throughput capacity is rated at 456–476 t/h with an energy consumption of 17.2–21.9 kWh/h at that throughput. The working aisle width required for a 1,000 × 1,200 mm pallet turned crossways is 4,999 mm, and for an 800 × 1,200 mm pallet lengthways it is 5,199 mm. The turning radius is 3,049 mm, and the smallest pivot point distance is 877 mm. Front and rear track widths are 1,561 mm and 1,432 mm respectively. Axle loads with load are 21,306 kg front and 2,124 kg rear; without load they are 7,097 kg front and 8,333 kg rear.
The hydraulic system provides a working pressure of 250 bar for attachments, with an oil flow of 60 l/min. The machine is equipped with third and fourth hydraulic valves, allowing the connection and operation of a wide range of attachments. The braking system is mechanically and hydraulically operated.
Operator comfort and safety features are well appointed. The truck is fitted with a full enclosed cabin, heating, exterior mirrors, and a rotating beacon light. The operator sound pressure level is below 70 dB(A), and whole-body vibration is below 0.7 m/s² in accordance with EN 13059. A DIN 15170 bolt-type drawbar coupling is also fitted. The internal stock reference for this listing is 5886.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
