1991 - Ullco Beverage Machine()
- Listing No
- 940418
- Year
- 1991
- Manufacturer
- Ullco
- Model
- Condition
- Used
- Location
- Germany
- Price
- POA
- Description
-
Vertical 6 bar stainless steel pressure tank with dished ends and various fittings and equipment. Additional title: vertical stainless steel tank Volume: 10560 l Fo Uexlpgnopngn Ieft Max. pressure: 6 bar test pressure 7,8 bar Max. temp.: 10 °C Length: 1900 mm Width: 1900 mm Height: 4770 mm Material: stainless steel 1.4301 (AISI 304) Base construction: vertical tank with dished bottom and pipe feet Features: Shell-manhole, level-display-hose, tank fittings: sampler, spray ball, bunging device, pressure gauge, safety valve, vacuum flap Request more information Request more information Already requested
About this machine
This Ullco Beverage Machine is a vertical stainless steel pressure tank — sometimes referred to as a pressure vessel — designed for the storage and handling of beverages under controlled pressure and temperature conditions. It is offered here as a used unit, manufactured in 1991 and currently located in Germany.
The tank has a total volume of 10,560 litres and is rated to a maximum working pressure of 6 bar, with a test pressure of 7.8 bar. The maximum permitted temperature is 10 °C, making it well suited to the cold storage of carbonated or otherwise pressurised beverages. The vessel is constructed from stainless steel grade 1.4301, the European designation for AISI 304, a widely used food-grade austenitic stainless steel valued for its corrosion resistance and ease of cleaning.
The tank is configured vertically with dished ends — a dished bottom supported on pipe feet — and its overall footprint measures 1,900 mm in diameter (both length and width), with a total height of 4,770 mm. The base construction on pipe feet allows for standard forklift or lifting access beneath the vessel.
The tank is fitted with a comprehensive set of fittings and ancillary equipment. A shell manhole provides internal access for inspection and cleaning. A level display hose gives a visible indication of fill level from the outside. Process fittings include a sampler port for drawing product samples, a spray ball for CIP (clean-in-place) internal cleaning, and a bunging device for sealing. Safety and monitoring equipment comprises a pressure gauge and a safety valve, with a vacuum flap providing protection against negative pressure conditions.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
