1991 - Ullmann Beverage Machine()
- Listing No
- 940496
- Year
- 1991
- Manufacturer
- Ullmann
- Model
- Condition
- Used
- Location
- Germany
- Price
- POA
- Description
-
Vertical 6 bar stainless steel pressure tank with dished ends and various fittings and equipment. Additional title: vertical stainless steel tank Volume: 10560 l Max. working overpressure: 6 bar test pressure: 7,8 bar Max. working temperature: 10 °C Length: 1900 mm Width: 1900 mm Height: 4770 mm Material: stainless steel 1.4301 (AISI 304) Position: standing on 3 pipefeet Fs Upjxlpf Dengnvoft Base construction: bottomed shells Features: Cleaning air/valve combination, cleaning line, CIP spray head, manhole, hose level indicator, sampling tap, pressure gauge, bunging device, safety valve, vacuum flap Request more information Request more information Already requested
About this machine
This Ullmann beverage machine is a vertical stainless steel pressure tank designed for the storage and handling of beverages under controlled pressure conditions. Such tanks — sometimes referred to as pressure vessels or process tanks in food and beverage contexts — are widely used in brewing, soft drink production, dairy, and related liquid processing industries to hold, condition, or transfer product under hygienic, pressurised conditions.
The tank has a total volume of 10,560 litres and is constructed from stainless steel grade 1.4301 (AISI 304), a food-grade austenitic alloy chosen for its corrosion resistance and ease of cleaning. The vessel features dished ends and stands vertically on three pipe feet, giving it a footprint of 1,900 mm × 1,900 mm and an overall height of 4,770 mm. Its maximum working overpressure is 6 bar, with a test pressure of 7.8 bar, and the maximum working temperature is 10 °C, indicating it is configured for chilled or cold-process applications.
The tank is equipped with a comprehensive set of fittings and ancillary components. These include a cleaning air and valve combination, a dedicated cleaning line, and a CIP (clean-in-place) spray head, supporting in-place sanitation without dismantling the vessel. A manhole provides access for inspection and manual cleaning when required. Level monitoring is handled by a hose level indicator, while a sampling tap allows product samples to be taken during operation. Additional fittings include a pressure gauge, a bunging device, a safety valve, and a vacuum flap, the last two providing protection against overpressure and negative pressure conditions respectively.
The machine is offered in used condition and is located in Germany, from 1991.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
