2018 - Vögele 1300-3I Asphalt Paver()
- Listing No
- 677110
- Year
- 2018
- Manufacturer
- Vögele
- Model
- Super 1300-3I
- Condition
- Used
- Location
- Netherlands
- Price
- €81,700
- Description
-
Screed AB340-3 TV with electrical heating (from 1,8 till 3,4 meter + additional extensions ON REQUEST), leveling system: VOGELE NIVELTRONIC PLUS (2x leveling sensors, 1x slope sensor, set wires), AutoSet Basic, 4x cyl engine DEUTZ TCD 3.6 L 4 / (output 74.4 kW), emission norm: EU stage 3b/ US tage TIER 4 laydown rate up to 350 t/hours, max. layer thickness 25 cm, hopper capacity 10 tonnes, pave speed up to 30 m/min, mechanical lifting system side plates, hardtop with wide sunshides, side warming, ErgoPlus operating system, halogen lights, CE- certified, EPA- certified, general condition: good working. = More information = Year of manufacture: 2018 GVW: 10.800 kg Screed AB340-3 TV with electrical heating (from 1,8 till 3,4 meter + additional extensions ON REQUEST), leveling system: VOGELE NIVELTRONIC PLUS (2x leveling sensors, 1x slope sensor, set wires), AutoSet Basic, 4x cyl engine DEUTZ TCD 3.6 L 4 / (output 74.4 kW), emission norm: EU stage 3b/ US tage TIER 4 laydown rate up to 350 t/hours, max. layer thickness 25 cm, hopper capacity 10 tonnes, pave speed up to 30 m/min, mechanical lifting system side plates, hardtop with wide sunshides, side warming, ErgoPlus operating system, halogen lights, CE- certified, EPA- certified, general condition: good working. = Weitere Informationen = Baujahr: 2018 zGG: 10.800 kg Produktionsår: 2018 Totalvægt: 10.800 kg Año de fabricación: 2018 PBV: 10.800 kg Année de construction: 2018 PBV: 10.800 kg Screed AB340-3 TV with electrical heating (from 1,8 till 3,4 meter + additional extensions ON REQUEST), leveling system: VOGELE NIVELTRONIC PLUS (2x leveling sensors, 1x slope sensor, set wires), AutoSet Basic, 4x cyl engine DEUTZ TCD 3.6 L 4 / (output 74.4 kW), emission norm: EU stage 3b/ US tage TIER 4 laydown rate up to 350 t/hours, max. layer thickness 25 cm, hopper capacity 10 tonnes, pave speed up to 30 m/min, mechanical lifting system side plates, hardtop with wide sunshides, side warming, ErgoPlus operating system, halogen lights, CE- certified, EPA- certified, general condition: good working. = Meer informatie = Bouwjaar: 2018 GVW: 10.800 kg Rok produkcji: 2018 Dopuszczalna masa całkowita (dmc.): 10.800 kg Ano de fabrico: 2018 GVW: 10.800 kg Год выпуска: 2018 Полная масса автомобиля: 10.800 kg Byggnadsår: 2018 GVW: 10.800 kg
About this machine
This is an asphalt paver – a self-propelled road-laying machine used to distribute and compact asphalt mixtures across road surfaces with precision and consistency. Vögele is a leading manufacturer of paving equipment, serving construction and civil engineering contractors worldwide.
The machine is equipped with a Screed AB340-3 TV featuring electrical heating capability, with a working width adjustable from 1.8 to 3.4 metres, and additional screed extensions available on request. Levelling is managed by the Vögele Niveltronic Plus system, which comprises two levelling sensors, one slope sensor, and the associated wire set for automated grade control. The paver is fitted with AutoSet Basic technology for operator assistance.
Power comes from a four-cylinder Deutz TCD 3.6 L 4 engine rated at 74.4 kW output. The machine meets EU Stage 3b and US Tier 4 emissions standards. Maximum laying rate reaches 350 tonnes per hour, with a paving speed capability of up to 30 metres per minute. The hopper holds 10 tonnes of material, and the screed can lay asphalt to a maximum thickness of 25 centimetres.
The paver features a mechanical lifting system for the side plates, a hardtop cab with wide sun shades to protect the operator, and side warming for the screed. The operating system is Vögele's ErgoPlus design, and halogen lighting is installed. Both CE and EPA certification are in place. The gross vehicle weight is 10,800 kilograms.
The machine is reported to be in good working condition and dates from 2018. It is located in the Netherlands.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
