Vögele 1800-3I Asphalt Paver()
- Listing No
- 681042
- Year
- Manufacturer
- Vögele
- Model
- Super 1800-3I
- Condition
- Used
- Location
- Netherlands
- Price
- POA
- Description
-
Screed AB500-3 TV electrical heated (working width from 2,5 till 5,0 meter), high leveling system: VOGELE Niveltronic Plus (2x leveling sensors, 1x slope sensor, 2x ultrasonic auger sensors, set of wires), 6-cyl diesel engine type CUMMINS QSB 6.7 C-164 (output 125 kW) emission norm EU stage 3a /US Tier 4i, EPA- certified , Auto Set plus, laydown rate up to 700 t/hours, max. layer thickness 30 cm, hopper capacity 13 tonnes, pave speed up to 24 m/min, hydraulic lifting system side plates, hardtop with wide sunshides, side heating on screed plates, Ergoplus 3 operating system, CE- confirmity, PaveDock Assistant, beacon, general condition: good working. = More information = GVW: 19.650 kg Screed AB500-3 TV electrical heated (working width from 2,5 till 5,0 meter), high leveling system: VOGELE Niveltronic Plus (2x leveling sensors, 1x slope sensor, 2x ultrasonic auger sensors, set of wires), 6-cyl diesel engine type CUMMINS QSB 6.7 C-164 (output 125 kW) emission norm EU stage 3a /US Tier 4i, EPA- certified , Auto Set plus, laydown rate up to 700 t/hours, max. layer thickness 30 cm, hopper capacity 13 tonnes, pave speed up to 24 m/min, hydraulic lifting system side plates, hardtop with wide sunshides, side heating on screed plates, Ergoplus 3 operating system, CE- confirmity, PaveDock Assistant, beacon, general condition: good working. = Weitere Informationen = zGG: 19.650 kg Totalvægt: 19.650 kg PBV: 19.650 kg PBV: 19.650 kg Screed AB500-3 TV electrical heated (working width from 2,5 till 5,0 meter), high leveling system: VOGELE Niveltronic Plus (2x leveling sensors, 1x slope sensor, 2x ultrasonic auger sensors, set of wires), 6-cyl diesel engine type CUMMINS QSB 6.7 C-164 (output 125 kW) emission norm EU stage 3a /US Tier 4i, EPA- certified , Auto Set plus, laydown rate up to 700 t/hours, max. layer thickness 30 cm, hopper capacity 13 tonnes, pave speed up to 24 m/min, hydraulic lifting system side plates, hardtop with wide sunshides, side heating on screed plates, Ergoplus 3 operating system, CE- confirmity, PaveDock Assistant, beacon, general condition: good working. = Meer informatie = GVW: 19.650 kg Dopuszczalna masa całkowita (dmc.): 19.650 kg GVW: 19.650 kg Полная масса автомобиля: 19.650 kg GVW: 19.650 kg
About this machine
This is an asphalt paver, a self-propelled road construction machine used to lay and finish asphalt surfaces on highways, roads, and airport runways. Vögele is a established manufacturer of road paving equipment, producing a range of pavers and ancillary machines for the civil engineering and road-building industries.
The machine is fitted with an AB500-3 TV electrically heated screed with an adjustable working width ranging from 2.5 to 5.0 metres, allowing flexibility for different paving widths. The paver is equipped with Vögele's Niveltronic Plus automatic levelling system, which incorporates two levelling sensors, one slope sensor, and two ultrasonic auger sensors to ensure consistent asphalt layer thickness and surface accuracy during operation.
Power comes from a six-cylinder Cummins QSB 6.7 C-164 diesel engine rated at 125 kW, engineered to meet EU Stage 3a and US Tier 4i emission standards with EPA certification. The machine delivers a maximum laydown rate of 700 tonnes per hour and can pave at speeds of up to 24 metres per minute. Maximum compacted layer thickness is 30 centimetres. The hopper has a capacity of 13 tonnes, reducing reload frequency on job sites.
The paver features hydraulic lifting side plates for easy manoeuvring, a hardtop cabin with wide sunshades for operator protection, and side heating elements on the screed plates to maintain asphalt temperature during laying. It is controlled via the Ergoplus 3 operating system and includes PaveDock Assistant technology to support precise paving operations. A beacon is fitted for site safety. The machine carries CE marking and conforms to applicable machinery directives.
The unit is located in the Netherlands and is in good working condition. Its gross vehicle weight is 19,650 kilograms.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
