Vögele 1800-3I Asphalt Paver()
- Listing No
- 681123
- Year
- Manufacturer
- Vögele
- Model
- Super 1800-3I
- Condition
- Used
- Location
- Netherlands
- Price
- POA
- Description
-
Screed AB500-3 TV electrical heated (working width from 2,5 till 5,0 meter+additional extensions parts on request), high leveling system: VOGELE Niveltronic Plus (2x leveling sensors, 1x slope sensor, 2x ultrasonic auger sensors, set of wires), 6-cyl diesel engine type CUMMINS QSB 6.7 C-164 (output 125 kW) emission norm EU stage 3a /US Tier 4i, EPA- certified , Auto Set plus, laydown rate up to 700 t/hours, max. layer thickness 30 cm, hopper capacity 13 tonnes, pave speed up to 24 m/min, hydraulic lifting system side plates, hardtop with wide sunshides, side heating on screed plates, Ergoplus 3 operating system, CE- confirmity, PaveDock Assistant, beacon, general condition: good working. = More information = GVW: 19.950 kg Screed AB500-3 TV electrical heated (working width from 2,5 till 5,0 meter+additional extensions parts on request), high leveling system: VOGELE Niveltronic Plus (2x leveling sensors, 1x slope sensor, 2x ultrasonic auger sensors, set of wires), 6-cyl diesel engine type CUMMINS QSB 6.7 C-164 (output 125 kW) emission norm EU stage 3a /US Tier 4i, EPA- certified , Auto Set plus, laydown rate up to 700 t/hours, max. layer thickness 30 cm, hopper capacity 13 tonnes, pave speed up to 24 m/min, hydraulic lifting system side plates, hardtop with wide sunshides, side heating on screed plates, Ergoplus 3 operating system, CE- confirmity, PaveDock Assistant, beacon, general condition: good working. = Weitere Informationen = zGG: 19.950 kg Totalvægt: 19.950 kg PBV: 19.950 kg PBV: 19.950 kg Screed AB500-3 TV electrical heated (working width from 2,5 till 5,0 meter+additional extensions parts on request), high leveling system: VOGELE Niveltronic Plus (2x leveling sensors, 1x slope sensor, 2x ultrasonic auger sensors, set of wires), 6-cyl diesel engine type CUMMINS QSB 6.7 C-164 (output 125 kW) emission norm EU stage 3a /US Tier 4i, EPA- certified , Auto Set plus, laydown rate up to 700 t/hours, max. layer thickness 30 cm, hopper capacity 13 tonnes, pave speed up to 24 m/min, hydraulic lifting system side plates, hardtop with wide sunshides, side heating on screed plates, Ergoplus 3 operating system, CE- confirmity, PaveDock Assistant, beacon, general condition: good working. = Meer informatie = GVW: 19.950 kg Dopuszczalna masa całkowita (dmc.): 19.950 kg GVW: 19.950 kg Полная масса автомобиля: 19.950 kg GVW: 19.950 kg
About this machine
This is an asphalt paver—a self-propelled road-laying machine used to distribute and compact hot-mix asphalt over prepared surfaces. Vögele is an established manufacturer of paving equipment, recognised across the construction and road-building industries for high-precision machinery.
The machine is fitted with an AB500-3 TV electrically heated screed with an adjustable working width ranging from 2.5 to 5.0 metres, with provision for additional extension parts. The sophisticated Niveltronic Plus automatic leveling system comprises two leveling sensors, one slope sensor, two ultrasonic auger sensors, and a full wiring set, enabling precise grade and slope control during operation.
Power is supplied by a six-cylinder Cummins QSB 6.7 C-164 diesel engine rated at 125 kW and certified to EU stage 3a and US Tier 4i (EPA) emission standards. The paver achieves a maximum laydown rate of 700 tonnes per hour and a paving speed up to 24 metres per minute. Maximum layer thickness is 30 centimetres, with a hopper capacity of 13 tonnes. Screed-plate side heating is integrated to maintain asphalt temperature during paving.
Additional equipment includes an Ergoplus 3 operating system, Auto Set plus functionality, a hardtop cabin with wide sunshades, hydraulic lifting side plates, PaveDock Assistant technology, and a beacon. The machine carries CE conformity marking. The gross vehicle weight is 19,950 kilograms.
The machine is in good working condition and currently located in the Netherlands.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
