2021 - Atlas Copco QAS 20 S5 Valid Inspection, *Guarantee! Diesel, 17 Diesel Generator()
- Listing No
- 810323
- Year
- 2021
- Manufacturer
- Atlas Copco
- Model
- QAS 20 S5 Vali
- Condition
- Used
- Location
- Netherlands
- Price
- €9,800
- Description
-
Field of application: ConstructionTransport dimensions (LxWxH): 1.78x0.87x1.2Please contact PFEIFER GROUP (See no., See no., ) for more informationVerwendungszweck: BauwesenTransportabmessungen (L x B x H): 1.78x0.87x1.2Wenden Sie sich an PFEIFER GROUP (See no., See no., ), um weitere Informationen zu erhalten.Pfeifer Heavy Machinery B.V is an official Atlas Copco dealer.Manufacturer: Atlas Copco.Typ: QAS 20Building year: 2021Serial nr: ESF369004Fuel: DieselEngine Man. / typ:Kubota V2203-M-BG-ET03E18.2 kW - 24.7PS / 1500 rpmElectrical dataRated frequency: (1) Hz 50 | 60Rated voltage (2) V 400 | 480Prime power (PRP) kVA / kW 20 / 16 | 24,3/19,5Rated standby power (ESP) kVA / kW 22 / 18 | 27 / 21,5Power factor cos ? 0,8Rated current (PRP) A 29 | 30AltinatorModel: LEROY SOMER LSA 40 M5 C6/4Rated Output (ESP 27ºC): kVA 22 | 27.5Degree of protection / Insulation class: IP 23 / P2Noise LevelSound power level (LwA): dB(A) 88 | 92Sound pressure level (LpA) at 7m: dB(A) 60 | 64* 60Hz models available, please consult.* Other voltages available, please consult.More detailed pictures / product movie on our website.pfeifermachinery.comAbove specifications are subject to change without prior notice and subject to errors.Meer informatieToepassingsgebied: BouwAfmetingen (LxBxH) (m): 1.78x0.87x1.2Neem voor meer informatie contact op met PFEIFER GROUP (See no., See no., ) Poids à vide : 795kg, Référence parc : A159E96E, Numéro de série : ESF369004, Poids à vide : 795kg, Nombre d'heures du moteur : 7819, Informations Moteur : Kubota, Puissance apparente : 20kVA, Poids : 0.795kg, Type d'intérieur : Autre, Type de pneus : Simples, Marque du moteur : Kubota
About this machine
The Atlas Copco QAS 20 S5 is a diesel generator designed for construction and transport applications. Atlas Copco is a leading manufacturer of power and compressed air equipment serving industrial, construction, and infrastructure sectors worldwide. This unit delivers reliable electrical power for on-site construction work and mobile operations where mains supply is unavailable or impractical.
This 2021 model is powered by a Kubota V2203-M-BG-ET03E diesel engine rated at 18.2 kW (24.7 PS) operating at 1500 rpm. The generator is equipped with a Leroy Somer LSA 40 M5 C6/4 alternator. Electrical output is configured for dual operation: at 50 Hz it produces 20 kVA (16 kW) prime power or 22 kVA (18 kW) rated standby power at 400 volts; at 60 Hz the outputs rise to 24.3 kVA (19.5 kW) prime power or 27 kVA (21.5 kW) standby power at 480 volts. The power factor is rated at 0.8, with a prime power current of 29 A at 50 Hz and 30 A at 60 Hz. The alternator is built to IP 23 protection class with P2 insulation class.
Noise levels are moderate for the category: sound power is rated at 88 dB(A) at 50 Hz and 92 dB(A) at 60 Hz; sound pressure at 7 metres is 60 dB(A) and 64 dB(A) respectively. The unit weighs 795 kg empty and measures 1.78 metres long, 0.87 metres wide, and 1.2 metres high, making it compact and transportable for construction sites. The engine has logged 7819 operating hours. Serial number ESF369004. The machine carries a valid inspection and guarantee.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
