1996 - Ferromatik Milacron K75-S 2FARBEN Injection Molding()
- Listing No
- 1216884
- Year
- 1996
- Manufacturer
- Ferromatik
- Model
- K75-S 2FARBEN
- Condition
- Used
- Location
- Germany
- Price
- $3,900
- Description
-
full functional 2-colour /2 component injection molding machine K75-S 2F in L-Format Year 1996 Internationale Size 750H 200/100 L working hours: 32750 h controller: IQT 6 (german Text) clamping unit (extende tie bars +200mm) clamping force: 750 kN/ 75 tons distanc. tie bars: 420 x 420 mm platens dist. max: 850 mm (max) tool height: 400 mm (min) platens size: 605 x 605 mm ejector force: 34 kN ejector stroke: 150 mm centering: 125 mm (nozzle/ejtector plate) injection units +++1. Aggregat+++ horizontal injection unitt (intern. size 200) screw diameter: 30 mm shot volume: 85 ccm injection pressure 2350 bar 4 x heating zones +++2.Aggregat+++ vertical injection unit (intern. Size. 100) screw diameter 25 mm shot volume: 49 ccm injection pressure 2022 bar 3 x heating units Extras accumulator core pull water battery hopper Dimensions /Elektric Motor 30 KW Heating 11,7 KW weight: 5100 kg dimensions: 4,5 x 1,5 x 2,5 (LxBxT) Painting: RAL 7016, 7035, 1012 De A Eqziecud Nhs Nsup available available now at our storage Hannover/Germany all our offered machines are in our own property Request more information Request more information Already requested
About this machine
This Ferromatik Milacron K75-S 2FARBEN is a used injection molding machine — sometimes referred to as an injection moulding press — built for the production of plastic components through high-pressure injection of molten material into a closed mould. Configured specifically for two-colour, two-component moulding, it is capable of producing parts from two distinct materials or colours in a single cycle, a capability that broadens its application across automotive, consumer goods, and technical plastics manufacturing. Ferromatik is a well-established German manufacturer with a long history of producing precision injection moulding equipment for industrial plastics processing.
This machine dates from 1996 and is presented in fully functional used condition, having logged 32,750 operating hours. It is arranged in L-format and carries the international size designation 750H 200/100 L. The control system is an IQT 6 unit with German-language interface.
The clamping unit is equipped with extended tie bars (+200 mm) and delivers a clamping force of 750 kN (75 tonnes). The tie bar spacing is 420 × 420 mm, with a maximum platen distance of 850 mm and a minimum tool height of 400 mm. Platens measure 605 × 605 mm. The ejector delivers 34 kN of force over a stroke of 150 mm, and centering diameter at both the nozzle and ejector plate is 125 mm.
The machine carries two independent injection units. The first is a horizontally oriented unit of international size 200, fitted with a 30 mm screw, offering a shot volume of 85 cc and a maximum injection pressure of 2,350 bar, with four heating zones. The second is a vertically oriented unit of international size 100, fitted with a 25 mm screw, offering a shot volume of 49 cc and a maximum injection pressure of 2,022 bar, with three heating zones.
Additional equipment includes an accumulator, core pull, water battery, and a hopper. The main motor is rated at 30 kW and the heating system at 11.7 kW. The machine weighs 5,100 kg and measures 4.5 × 1.5 × 2.5 metres (L × W × H). External paintwork is finished in RAL 7016, 7035, and 1012. The machine is currently in stock at a storage facility in Hannover, Germany.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
