FMB Jupiter C1000 Automatic CNC Band Saw()
- Listing No
- 955334
- Year
- Manufacturer
- FMB
- Model
- Jupiter C1000
- Condition
- Used
- Location
- Belgium
- Price
- POA
- Description
-
Automatic band saw machine for cuts from 0° to 60° right.nbsp Cap: round 260 mm - square 260 x 260 mm Cap: 45° round 260 mm -nbsp;square 260 x 260 mm Cap:nbsp;60°nbsp;round 180 mm -nbsp;square 180 x 180 mm CNC Feed stroke 1000 mm + unlimited repositioningnbsp Variable Speed: 16 - 120 m/min Air: max 6 bar Depth of throat: 310 mm Max height of workpiece: 260 mm Sawspeed: 16 > 120 m/min Length of band saw: 3300 x 27 x 0,9 mm Power needed: 3 kW
About this machine
The FMB Jupiter C1000 is a used automatic horizontal band saw — sometimes referred to as a metal cutting bandsaw — designed to make precise straight and mitre cuts through bar stock, tube, and solid sections in metalworking and fabrication environments. FMB is a well-regarded German manufacturer specialising in band saw machinery, serving industries that require accurate, high-volume cutting of metal profiles and structural materials.
This machine is configured for automatic CNC-controlled cutting and covers a mitre range from 0° to 60° right. At 0° and 45°, it handles round bar up to 260 mm in diameter and square or rectangular sections up to 260 × 260 mm. At 60°, the capacity reduces to 180 mm round and 180 × 180 mm square, which is consistent with the geometry of angled cutting. The CNC feed stroke measures 1,000 mm with unlimited repositioning, making it well suited to repetitive, programmed cutting cycles where multiple lengths are produced from a single bar without manual intervention.
The blade speed is variable across a wide range of 16 to 120 metres per minute, allowing the operator to optimise the cutting speed to suit different materials and cross-sections. The depth of throat is 310 mm, and the maximum workpiece height is 260 mm. The band saw blade itself measures 3,300 × 27 × 0.9 mm. The machine requires a power supply of 3 kW and uses compressed air at a maximum of 6 bar for clamping and feed functions.
The machine is located in Belgium and is offered in used condition.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
