2015 - Engel Victory 200 40 Injection Moulding()
- Listing No
- 1153435
- Year
- 2015
- Manufacturer
- Engel
- Model
- Victory 200 40
- Condition
- Used
- Location
- Germany
- Price
- POA
- Description
-
This Engel VICTORY 200/40 tech was manufactured in 2015. It features a tie-bar-less design, enhancing flexibility and accessibility for various mould sizes. With a clamping force of 40 tons and a screw diameter of 25 mm, it supports a maximum injection volume of 69 cm³. The machine includes a robot interface (Euromap 67) and is still in production, showcasing its reliability and excellent condition. Contact us for more information about this machine. Location: RO Screw Diameter: 25 mm Injection unit: 200 Maximum injection volume: 69 cm³ Minimum mould height: 193 mm Maximum mould height: 599 mm Platen opening stroke: 405 mm Platen dimensions (W x L): 500 x 450 mm Tie bars: Tie-bar-less design Heater power: 6.85 kW Number of electrical connection pins: 16 Injection nozzle radius (tip): R35 Centering ring diameter: 125 mm Robot interface: Euromap 67 Condition: Excellent Status: In production Additional equipment Robot (equipped brand/model not specified)
About this machine
This Engel Victory 200 40 is a used injection moulding machine — sometimes referred to as a plastic injection moulding press — designed to form plastic components by injecting molten material into a closed mould under controlled pressure. Engel is a well-established Austrian manufacturer of injection moulding machinery, serving industries including automotive, medical, packaging, and consumer goods, and is widely regarded as one of the leading names in plastics processing equipment worldwide.
Built in 2015 and currently located in Germany, this machine is reported to be in excellent condition and was still active in production at the time of listing, speaking to its reliability and maintained state. One of its defining characteristics is a tie-bar-less frame design, which removes the horizontal bars that would otherwise restrict platen access. This configuration allows larger or irregularly shaped moulds to be mounted more easily and gives operators unobstructed access to the clamping area, making it particularly well suited to moulding complex or wide-flanged parts.
The machine delivers a clamping force of 40 tonnes and is equipped with a 25 mm screw diameter, supporting a maximum injection volume of 69 cm³. Mould height can be accommodated within a range of 193 mm to 599 mm, and the platen opening stroke measures 405 mm. The platen dimensions are 500 mm wide by 450 mm long, defining the available footprint for mould installation.
Heater power is rated at 6.85 kW. The nozzle tip carries a radius of R35, and the centering ring diameter is 125 mm — both relevant parameters for matching tooling and hot-runner systems. The machine features 16 electrical connection pins and is equipped with a Euromap 67 robot interface, the standardised communication protocol that allows direct integration with robotic handling equipment. A robot is included with this listing, though its brand and model are not specified.
The combination of tie-bar-less access, a Euromap 67 interface, and an included robot makes this a capable, automation-ready cell suited to short-cycle, precision moulding applications.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
