2001 - Homag KFR20 16 QA 15 Edge Bander

About this machine

This Homag KFR20 16 QA 15 is a used edge bander — sometimes referred to as an edge banding machine — dating from 2001 and currently located in Belgium. Edge banders are used in panel processing and furniture manufacturing to apply edging material to the exposed sides of boards and panels, producing a clean, finished appearance. Homag is a well-established German manufacturer of woodworking machinery, widely recognised for its processing lines, edge banding equipment, and panel handling systems serving the furniture, joinery, and timber industries.

This particular listing comprises a complete four-side squaring and edge banding line made up of two machines working in sequence, offering a high degree of processing capability across a wide range of panel sizes and edge types. Both machines handle coil edges from 0.3 to 3 mm and strip edges from 0.4 to 20 mm, and both accept panels from 8 to 60 mm in thickness. Feed speed on each machine is variable between 10 and 40 metres per minute, and both are controlled via an NC 21 control system. Each machine runs on a rolling chain feed configuration with a fixed right side and moving left side, and both are equipped with an entry fence suited to veneered panels.

Machine 1 accepts panels up to 1,500 mm in width. Its equipment includes a 1+1 compact-twin hogger driven by two 6.6 kW motors, a 1+1 compact hot melt unit A20 with panel edge pre-heating, a glue roller Q34, a twin coil magazine, and lateral pressure rollers with anti-stick application. There is 1+1 free space provision for solid wood edges up to 2.54 metres in length. Trimming is handled by 1+1 rough trimming units at 2 × 1.5 kW and 1+1 fine or radius trimming units at 2 × 0.4 kW, capable of processing edges up to 6 mm. Two 1+1 universal shapers, each rated at 8.1 kW, are fitted alongside a 1+1 edge sander KS 10, a 1+1 disc sander DS 40, and a further 1+1 disc sander DS 40. Machine 1 connects to an angular transfer unit to the right, designated TWR 24/30/12/S, which handles panels ranging from 250 to 1,200 mm in width, 250 to 3,000 mm in length, and 8 to 45 mm in thickness.

Machine 2 features an infeed magazine TW 24, pop-up dogs, automatic height setting, and a middle support, making it suited to handling larger panels up to 2,500 mm in width. Its tooling layout closely mirrors that of Machine 1, with 1+1 compact-twin hogger units at 2 × 6.6 kW, a 1+1 compact hot melt unit A20 with pre-heating, glue roller Q34, twin coil magazine, and lateral pressure rollers with anti-stick application. Machine 2 additionally includes 1+1 end trims HL 05 powered by two 0.4 kW motors and 1+1 contour trimming FF 12 units driven by four 0.4 kW motors, providing greater edge profile flexibility. Rough trimming at 2 × 1.5 kW and fine or radius trimming at 2 × 0.4 kW are both present, as are two 1+1 universal shapers at 8.1 kW each, a 1+1 edge sander KS 10, and two sets of 1+1 disc sanders DS 40. The line is offered in used condition.

This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
