2020 - IKA MHD2000 5 Atex Mixer Blender
()- Listing No
- 1184264
- Year
- 2020
- Manufacturer
- IKA
- Model
- MHD2000 5 Atex
- Condition
- Used
- Location
- Netherlands
- Price
- POA
- Description
-
Location: Barneveld Type: MHD 2000/05-ATEX No: 200023306 Material: Stainless steel 1.4306 (304L) Motor: 7,5 kW, 400/690 volt, 2910 rpm, (Ex) Rotor: 60 mm Continuous reactor: check Rotor sizes: Dia. 60x150 mm Inlet: DN50 Outlet: DN32 Number of stages: 2 Capacity: 700 l/h Rotor speed: 6000 rpm Mounted on frame: check CE: check Floorspace: 0,70x0,40 m Total height: 1,20 m ATEX compatible: check Extra Specifications: Total cap. 700 l/h, solids cap. Max 500 l/h General Main Features Specified Features - Inline mixer Information
About this machine
This IKA MHD2000 5 Atex is an inline mixer and blender — sometimes referred to as an inline homogeniser — designed to continuously process and blend liquid and solid-liquid mixtures as they flow through a pipeline. IKA is a well-established German manufacturer of mixing, dispersing, and process technology equipment, supplying industries including chemicals, pharmaceuticals, food processing, and cosmetics with precision laboratory and industrial-scale machinery.
This unit is a two-stage inline mixer configured as a continuous reactor, meaning it processes product in a flowing stream rather than in batches. It is mounted on a frame with a floor footprint of 0.70 × 0.40 metres and a total height of 1.20 metres, making it a compact installation. The machine carries CE certification and is fully ATEX-rated for use in potentially explosive atmospheres, with the drive motor accordingly specified as an Ex-protected unit.
The motor is rated at 7.5 kW and operates on 400/690 volt supply at 2,910 rpm. The rotor measures 60 mm in diameter and 150 mm in length, and is driven at a rotor speed of 6,000 rpm to deliver high-shear mixing action. The process connections are DN50 on the inlet and DN32 on the outlet. Total throughput capacity is 700 litres per hour, with a maximum solids-handling capacity of 500 litres per hour.
Wetted parts are constructed from stainless steel grade 1.4306 (equivalent to 304L), providing good corrosion resistance for a broad range of process media. The machine carries serial number and is located in Barneveld, Netherlands. It was manufactured in 2020 and is offered in used condition.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
