Pendraulik WDV 7.5 – Dissolver Mixer Blender
()- Listing No
- 1184228
- Year
- Manufacturer
- Model
- Condition
- Used
- Location
- Netherlands
- Price
- POA
- Description
-
Location: Germany Type: WDV 7,5 Material: Stainless steel Motor: check Dissolver: check Shaft length: 1370 mm Disc diameter: max 200 mm Between shaft and frame: 500 mm With variable speed drive: 360-1800 rpm With mechanical lifting: check With switch: check Floorspace: 0,56 m CE: check Total height: 3,45 m ATEX compatible: check Extra Specifications: drum cap. 400-1350 kg, max drum dia. 600-800 mm, with wing mixer and Stahl control merk: Pendraulik General Main Features Specified Features - Dissolver Information
About this machine
The Pendraulik WDV 7.5 is a used dissolver — a type of mixer and blender, sometimes referred to as a high-speed disperser — designed for mixing, blending, and dispersing materials in industrial production processes. Pendraulik is a well-established Dutch manufacturer specialising in laboratory and industrial mixing equipment, with its dissolvers widely used in the paints, coatings, inks, adhesives, and chemical industries.
This machine is constructed in stainless steel throughout, making it well suited to process environments with hygiene or corrosion-resistance requirements. It is equipped with a dissolver disc with a maximum diameter of 200 mm, mounted on a shaft with a total length of 1,370 mm. The distance between the shaft and the frame measures 500 mm, providing working clearance appropriate for the drum sizes this unit accommodates. A variable-speed drive delivers a speed range of 360 to 1,800 rpm, allowing the operator to tailor agitation intensity to the specific product and stage of the mixing process. The machine also includes a wing mixer, broadening its capability to handle products that benefit from gentler, broader circulation in addition to high-speed dispersion.
Drum handling is supported by a mechanical lifting mechanism, which raises and lowers the dissolver head to engage with or clear the drum. The unit is designed to work with drums ranging from 600 to 800 mm in diameter, accommodating batch weights of 400 to 1,350 kg. Total machine height is 3.45 metres, and the floor footprint measures 0.56 m², making it a relatively compact installation for the capacity it offers.
Control is handled through a Stahl control panel with an integrated switch, and the machine carries CE certification. It is also noted as ATEX compatible, meaning it is suitable for use in potentially explosive atmospheres — a relevant feature for operations handling flammable solvents or dusts. The machine is located in Germany and is offered in used condition.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
