1993 - A. Berents RW 1000 Processing vessel Mixer Blender()
- Listing No
- 1182000
- Year
- 1993
- Manufacturer
- Model
- Condition
- Used
- Location
- Netherlands
- Price
- POA
- Description
-
Location: Barneveld Type: RW 1000 No: 011/6-469 Working pressure: 2 Bar Vacuum possible: check Working pressure jacket: 6 Bar Material: Stainless steel 1.4552 Volume: 1435 Ltr Motor: 23 kW, 380 volt, 3500 rpm Closed stirring vessel: check Capacity: 1434 l., (1000 l.) Vessel sizes: Dia. 1500x1300 mm Dished bottom: check Manhole: DN1500 Top connections: check Outlet: DN80 With jacket: check volume 77 l Max. temperature: 133°C With homogeniser: check Total height: 3,00 m Mounted on legs: check Floorspace: 1,90x1,55 m Extra Specifications: With pressure vessel, volume 41 l. pneumatic hood lifter Drive for scraper will be included merk: A. Berents General Pressure Main Features Specified Features - Processing vessel Information
About this machine
This A. Berents RW 1000 is a mixer and blender — sometimes referred to as a mixing vessel or blending tank — designed for processing, blending, and homogenising liquid or semi-liquid products in industrial and food-related applications. A. Berents is a Dutch manufacturer known for producing stainless steel process vessels and mixing equipment for the food, dairy, and chemical processing industries.
The vessel is constructed from stainless steel grade 1.4552 and has a total volume of 1,435 litres, with a working capacity of 1,000 litres. The cylindrical body measures 1,500 mm in diameter by 1,300 mm in height, features a dished bottom, and is mounted on legs, giving a total installation height of 3.00 metres. The floor footprint is 1.90 by 1.55 metres, making it a compact unit relative to its capacity.
This is a closed stirring vessel rated for a working pressure of 2 bar, with vacuum capability also available. The vessel is fitted with a jacket — with a jacket volume of 77 litres — rated to a working pressure of 6 bar, allowing for heating or cooling of the vessel contents up to a maximum temperature of 133°C. A manhole of DN1500 provides access to the interior, the outlet is DN80, and top connections are present. The vessel is also equipped with a homogeniser for achieving fine, uniform product consistency.
The drive unit is a 23 kW electric motor running on 380 volt three-phase supply at 3,500 rpm. A scraper drive is included with the sale, allowing wall-scraping agitation to prevent product build-up on the vessel interior. The unit also comes with a separate pressure vessel of 41 litres and a pneumatic hood lifter for convenient access to the vessel opening. The machine carries serial number 011/6-469 and is located in Barneveld, Netherlands, offered in used condition from 1993.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
