2005 - Deckel Maho DMC 60 T 2-FACH Wechseltisch WZ 120 Fach Machining Center()
- Listing No
- 943376
- Year
- 2005
- Manufacturer
- Deckel Maho
- Model
- DMC 60 T
- Condition
- Used
- Location
- Germany
- Price
- POA
- Description
-
For sale is a machining center by Deckel Maho, model DMC 60 T. The machine is in good condition and ready for immediate use. Technical data: Year of manufacture: 2005 Operating hours: 39,256 Power-on hours: 72,107 X-axis travel: 780 mm Y-axis travel: 560 mm Z-axis travel: 560 mm Control: iTNC 530 Heidenhain Spindle speed range: 20 - 12,000 rpm Main spindle drive power: 28 / 19 kW Max. torque: 125 Nm Tool holder: SK 40 B-axis infinitely adjustable: 150° (-120/+30)° Number of pallets: 2 Pallet size: 630 x 500 mm Max. load: 400 kg Table speed range: max. 30 rpm Number of tool stations: 120 positions Max. tool diameter: 80 mm Max. tool diameter with adjacent pocket empty: 160 mm Max. tool length: 315 mm Max. tool weight: 8 kg Rapid traverse ( X / Y / Z ): 50 m/min Feed rate: 20 - 15,000 mm/min Total power requirement: 64.2 kVA Fpsc N Aowtft Njqyyob Machine weight: approx. 12.0 t Floor space required: approx. 7.0 x 7.0 x 2.8 m Included in the offer: Documentation, chip conveyor, coolant system, high-pressure coolant 40 bar through spindle, paper band filter, 2-position pallet changer, tool breakage monitoring Accessories such as clamping devices or tool holders are NOT included in the offer. Transport and loading can be organised throughout Europe at additional cost upon request. Prices are subject to VAT. Inspection is possible by appointment. Please contact us; our team will be happy to assist you. Trade-in or exchange possible! Machinery purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality yet affordable metalworking machine for your production? Or do you want to sell yours? For further information or contact options, please visit our website. The listing was translated automatically. Translation errors are possible. Request more information Request more information Already requested
About this machine
This Deckel Maho DMC 60 T is a used machining center, a category of machine tool — sometimes referred to as a CNC machining center — designed to perform multiple precision metal-cutting operations such as milling, drilling, boring, and tapping on a single workpiece with automatic tool changing. Deckel Maho is a well-established German manufacturer of high-precision machine tools, widely recognised for producing machining centers and milling machines used in toolmaking, aerospace, automotive, and general engineering applications. This example was built in 2005 and is located in Germany, offered in good condition and described as ready for immediate use.
The machine has logged 39,256 operating hours and 72,107 power-on hours. Its three linear axes provide travels of 780 mm in X, 560 mm in Y, and 560 mm in Z. The B-axis is infinitely adjustable over a 150-degree range (−120° to +30°), giving the machine its 5-axis capability and allowing complex angled workpiece orientations without manual repositioning. Rapid traverse on all three linear axes reaches 50 m/min, and the feed rate is continuously variable from 20 to 15,000 mm/min.
The main spindle covers a speed range of 20 to 12,000 rpm, driven by a motor rated at 28 kW (19 kW continuous) and delivering a maximum torque of 125 Nm. Tooling is accommodated via an SK 40 taper interface. The chain-type tool magazine holds 120 positions, accepting tools up to 80 mm in diameter (or up to 160 mm when the adjacent pocket is left empty), up to 315 mm in length, and up to 8 kg in weight.
The machine is equipped with a 2-position pallet changer. Each pallet measures 630 × 500 mm and carries a maximum load of 400 kg, with a table rotation speed of up to 30 rpm. This twin-pallet arrangement allows one workpiece to be set up while machining continues on the other, reducing non-productive time. Control is provided by a Heidenhain iTNC 530 unit, a well-regarded conversational and DIN/ISO CNC system widely used in precision milling applications.
Included with the machine are documentation, a chip conveyor, a coolant system, high-pressure through-spindle coolant at 40 bar, a paper band filter, and tool breakage monitoring. Clamping devices and tool holders are not included. Total power consumption is 64.2 kVA, the machine weighs approximately 12.0 tonnes, and the required floor space is approximately 7.0 × 7.0 m with a height clearance of 2.8 m. Transport and loading across Europe can be arranged at additional cost.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
