2002 - GPI Mixer Blender()
- Listing No
- 1183268
- Year
- 2002
- Manufacturer
- GPI
- Model
- Condition
- Used
- Location
- Netherlands
- Price
- POA
- Description
-
Location: Barneveld Type: V-015 No: 22-175-1 Working pressure: 2 Bar Vacuum possible: check Material: Stainless steel 1.4404 (316L) Volume: 1800 Ltr Motor: 1,1 kW, 1400 rpm (EX) Closed stirring vessel: check Capacity: 1800 Ltr Vessel sizes: Dia. 1250x1500 mm Slope bottom: check Dished top side: check With cover: check with 2 CIP nozzle's Outlet: Dia. 25 mm Max. temperature: 150°C With paddle stirrer: check Speed mixing shaft: 35rpm With switchgear: check Total height: 2,0 m CE: check Mounted on legs: check with wheels Floorspace: 1,9x1,4 m ATEX compatible: check Extra Specifications: adjustable stirring speed by means of a frequency converter General Pressure Main Features Specified Features - Stirring vessel Information
About this machine
This GPI Mixer Blender is a used mixer and blender — sometimes referred to as a mixing vessel or blending tank — designed for the controlled blending, agitation, and homogenisation of liquid or semi-liquid products in industrial processing environments. GPI is a Dutch manufacturer known for producing process equipment for the food, chemical, and pharmaceutical industries.
This 2002 machine is located in Barneveld, Netherlands, and carries serial reference , type V-015. It is built entirely from stainless steel grade L), making it suitable for hygienic and corrosion-sensitive applications. The closed stirring vessel has a total volume and capacity of 1,800 litres, with vessel dimensions of 1,250 mm diameter by 1,500 mm height. The vessel features a sloped bottom and a dished top side, both of which aid in complete drainage and efficient product flow. A cover is fitted, equipped with two CIP (clean-in-place) nozzles to facilitate in-line cleaning without dismantling the vessel. The product outlet has a diameter of 25 mm.
The vessel operates at a working pressure of 2 bar and is capable of vacuum operation. Maximum process temperature is 150°C. Agitation is provided by a paddle stirrer driven by a 1.1 kW motor running at 1,400 rpm. The mixing shaft itself turns at 35 rpm, and stirring speed is adjustable by means of an integrated frequency converter, allowing the operator to fine-tune agitation intensity to suit the product being processed. The machine is supplied with its own switchgear and is ATEX compatible, making it suitable for use in potentially explosive atmospheres. The motor is of EX-rated specification, consistent with this ATEX classification. CE marking is present.
The unit is mounted on legs fitted with wheels, giving it a degree of mobility on the production floor. Its total height is 2.0 metres and its floor footprint measures 1.9 by 1.4 metres, providing a compact and manageable installation envelope for an 1,800-litre vessel.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
