2017 - Inotec 12000 LTR Mixer Blender()
- Listing No
- 1181548
- Year
- 2017
- Manufacturer
- Inotec
- Model
- 12000 LTR
- Condition
- Used
- Location
- Netherlands
- Price
- POA
- Description
-
Location: Barneveld No: IN289/17045 Material: Stainless steel 1.4404 (316L) Volume: 12000 Ltr Motor: 2,2 kW, 230/400 volt, 1465 rpm Closed stirring vessel: check Capacity: 14.400 l, (netto 12.000 l) Vessel sizes: Dia. 2300x3600 mm Dished bottom: check Dished top side: check Manhole: Dn500 Top connections: check Outlet: DN150 Max. temperature: 55°C With propellor stirrer: check Speed mixing shaft: 20-120 rpm Floorspace: 2,82 x 2,82 m CE: check Total height: 4,7 m Extra Specifications: Hanging vessel General Main Features Specified Features - Stirring vessel Information
About this machine
This Inotec 12000 LTR Mixer Blender is a used mixer and blender — sometimes referred to as a mixing vessel or agitator tank — designed for the blending and homogenisation of liquid products at industrial scale. Mixer and blenders of this type are widely used in the food, chemical, and pharmaceutical industries wherever large volumes of liquid or semi-liquid materials must be combined consistently and efficiently.
This particular unit is a closed stirring vessel constructed from stainless steel grade L), a corrosion-resistant alloy well suited to aggressive or hygiene-critical media. The vessel has a gross capacity of 14,400 litres and a net working volume of 12,000 litres. Its cylindrical shell measures 2,300 mm in diameter by 3,600 mm in height, with both a dished bottom and a dished top, giving it the structural integrity and drainage characteristics typical of high-specification process vessels. The unit is configured as a hanging vessel, suspended rather than floor-supported, which is a common arrangement in process plants where access beneath the vessel or integration with structural steelwork is required.
Mixing is performed by a propeller stirrer mounted on a shaft with a variable speed range of 20 to 120 rpm, allowing the operator to adjust agitation intensity to suit the product being processed. The drive is provided by a 2.2 kW motor running at 1,465 rpm on a 230/400 volt supply. The vessel is rated to a maximum operating temperature of 55°C.
Access and process connections are well specified. A DN500 manhole provides internal access for inspection and cleaning. The outlet is sized at DN150, and additional top connections are fitted. The vessel carries CE certification. Its overall footprint on the floor is 2.82 × 2.82 metres, and the total installed height is 4.7 metres.
Built in 2017 and offered in used condition, this machine is located in Barneveld, Netherlands, and is listed under reference number IN289/17045.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
