2014 - K-Tron Coperion K2-MV-T35 (with high shear mixer) Mixer Blender()
- Listing No
- 1178851
- Year
- 2014
- Manufacturer
- Model
- Condition
- Used
- Location
- Netherlands
- Price
- POA
- Description
-
Location: Barneveld Type: K2-MV-T35 No: 1400518/M-356290 Material: Stainless steel 1.4404, Stainless steel 1.4435 (316L) Motor: 0,55 kW 400 Volt Inlet diameter: 804 mm Screw diameter: 35 mm Pitch: 12,5 mm Screw length: 240 mm With hopper: check Capacity: 77 Ltr Hopper sizes: dia. 804x339,93 mm Inlet: dia. 804 mm Outlet: dia. 220 mm With motor: 0,55 kW 400 Volt Screw speed: max. 82 rpm With breaking/mixing shaft: check With switchgear: (as is) Floorspace: 1,2x1,2 m CE: check Total height: 2,6 m Extra Specifications: with twin screw feeder: coperion k-tron K-ML-KT20, 2014, (CE), with hopper: 7 Ltr., inlet: dia. 114,3 mm, outlet: 60,3 mm; with weight scale merk: K-Tron Coperion General Main Features Specified Features - Metering screw Metering screws Information
About this machine
This K-Tron Coperion K2-MV-T35 is a used mixer and blender — sometimes referred to as a mixing blender or process mixer — built for the controlled blending and metering of bulk materials. K-Tron Coperion is a well-established manufacturer of feeding, conveying, and mixing equipment, serving industries such as plastics, chemicals, food processing, and pharmaceuticals, and is recognised for precision loss-in-weight and volumetric feeding systems as well as bulk solids handling technology.
Manufactured in 2014 and carrying serial number 1400518/M-356290, the machine is constructed entirely in stainless steel grades 1.4404 and L), making it suited to applications where material purity and corrosion resistance are important. It is located in Barneveld, Netherlands, and carries CE certification.
The unit has a usable capacity of 77 litres and is driven by a 0.55 kW motor running on 400 V. The metering screw has a diameter of 35 mm, a pitch of 12.5 mm, and a length of 240 mm, with a maximum screw speed of 82 rpm. A breaking and mixing shaft is fitted, enabling active material conditioning alongside the metering function. The inlet diameter is 804 mm and the outlet diameter is 220 mm, and the machine is equipped with a hopper measuring 804 mm in diameter by 339.93 mm in height. Switchgear is included as-is. The machine occupies a floor footprint of 1.2 × 1.2 m and stands 2.6 m in total height.
Included with this unit is a Coperion K-Tron K-ML-KT20 twin-screw feeder, also from 2014 and CE-marked. This feeder is fitted with a 7-litre hopper, an inlet of 114.3 mm diameter, and an outlet of 60.3 mm diameter, and it incorporates an integrated weight scale for gravimetric dosing.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
