2003 - Pfaudler AE100 – GLASS- Mixer Blender()
- Listing No
- 1182024
- Year
- 2003
- Manufacturer
- Pfaudler
- Model
- AE100 - GLASS-
- Condition
- Used
- Location
- Netherlands
- Price
- POA
- Description
-
Location: Barneveld Type: AE 100 No: 128317 Working pressure: 6 Bar Vacuum possible: check Working pressure jacket: 6 Bar Vacuum possible jacket: check Material: Glass - Enamel (WWG-9115) Volume: 100 Ltr Motor: 1,5 kW, 500 volt, 1405 rpm, (Ex) Reactor: check Capacity: 138 l., (100 l.) Vessel sizes: Dia. 600x500 mm Dished bottom: check Dished top side: check Top connections: check Outlet: DN80 with valve With jacket: check volume 43 l Max. temperature: 25°C/+200°C With propellor stirrer: check Speed mixing shaft: 23-232 rpm Total height: 2,40 m CE: check Floorspace: 0,90x0,90 m ATEX compatible: check General Pressure Main Features Specified Features - Glass-lined Reactor Glass Reactors Information
About this machine
This Pfaudler AE100 is a glass-lined mixer and blender — sometimes referred to as a glass-lined reactor or stirred vessel — designed for mixing, blending, and reacting materials under controlled pressure and temperature conditions. Pfaudler is a well-established manufacturer specialising in glass-lined process equipment, serving the chemical, pharmaceutical, and fine chemical industries where corrosion resistance and product purity are critical requirements.
This unit dates from 2003 and is offered in used condition from Barneveld, Netherlands. The vessel has a nominal working volume of 100 litres, with a total capacity of 138 litres, and is constructed from glass-enamel material to specification WWG-9115, providing excellent resistance to corrosive media. The cylindrical vessel measures 600 mm in diameter by 500 mm in height, with both a dished bottom and a dished top side. The overall installed height of the unit is 2.40 metres, and its footprint is 0.90 × 0.90 metres.
The vessel is rated for a working pressure of 6 bar, with vacuum capability also confirmed. It is fitted with a heating/cooling jacket rated to the same 6 bar working pressure, with vacuum capability on the jacket as well; jacket volume is 43 litres. The operating temperature range extends from -25 °C to +200 °C. A DN80 outlet with valve is fitted, and top connections are present.
Agitation is provided by a propeller stirrer driven by a 1.5 kW motor rated at 500 volts and 1,405 rpm, with the mixing shaft delivering a variable speed range of 23 to 232 rpm. The motor is specified for use in explosive atmospheres (Ex-rated), and the unit carries ATEX compatibility as well as CE certification, making it suitable for hazardous area installations in compliance with European directives.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
