2007 - Pfaudler-Werke AE100 Mixer Blender()
- Listing No
- 1179347
- Year
- 2007
- Manufacturer
- Model
- Condition
- Used
- Location
- Netherlands
- Price
- POA
- Description
-
Location: Barneveld Type: AE100 No: 74686 Working pressure: 6 Bar Vacuum possible: check Working pressure jacket: 6 Bar Vacuum possible jacket: check Material: Glass - Enamel (PPG) Volume: 100 Ltr Motor: 1,5 kW, 400 volt, 1415 rpm, (Ex) Reactor: check Capacity: 138 l., (netto 100 l.) Vessel sizes: Dia. 500x931 mm Dished bottom: check Top connections: check Outlet: DN80 With jacket: check Volume 43 l Max. temperature: 25°C/+200°C With propellor stirrer: check Speed mixing shaft: 224rpm Mounted on legs: check CE: check Floorspace: 0,80x0,80 m Total height: 2,0 m Extra Specifications: pneumatic glass-lined outlet valve included merk: Pfaudler-Werke General Pressure Main Features Specified Features - Glass-lined Reactor Glass Reactors Information
About this machine
This Pfaudler-Werke AE100 is a mixer and blender — sometimes referred to as a mixing reactor or stirred vessel — designed for blending, reacting, and processing liquids or suspensions under controlled pressure and temperature conditions. Pfaudler-Werke is a well-established name in industrial process equipment, particularly known for manufacturing glass-lined vessels and reactors used in the chemical, pharmaceutical, and fine-chemical industries.
This unit is built from glass-enamel (PPG) lined steel, giving it excellent resistance to corrosion and chemical attack across a wide range of process media. The vessel has a gross capacity of 138 litres with a net working volume of 100 litres, and measures 500 mm in diameter by 931 mm in height, with a dished bottom. It is mounted on legs and has a total installed height of 2.0 metres, with a floor footprint of 0.80 × 0.80 metres.
The vessel is rated for a working pressure of 6 bar and is vacuum-capable. It is fitted with a jacket — also rated to 6 bar and vacuum-capable — with a jacket volume of 43 litres, allowing for heating or cooling of the vessel contents. The operating temperature range runs from -25 °C to +200 °C. Top connections are present, and the outlet is sized at DN80.
Agitation is provided by a propeller stirrer driven by a 1.5 kW explosion-proof (Ex) motor running at 400 V, 1415 rpm, with a mixing shaft speed of 224 rpm. A pneumatic glass-lined outlet valve is included with the unit.
The machine carries CE marking and was manufactured in 2007. It is located in Barneveld, Netherlands, and is offered in used condition with internal reference number 74686.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
