2013 - Zoatec Prozessbehaelter 600 Tank Container
()- Listing No
- 1180104
- Year
- 2013
- Manufacturer
- Model
- Condition
- Used
- Location
- Netherlands
- Price
- POA
- Description
-
Location: Barneveld Type: Prozessbehaelter 600 No: 103867-00 Working pressure: 3 Bar Vacuum possible: check Working pressure jacket: 3 Bar Vacuum possible jacket: check Material: Stainless steel Volume: 600 Ltr Closed stirring vessel: check Capacity: 600 Ltr. (max. 890 Ltr,) Vessel sizes: 1000x1350 mm Conical bottom: check Dished top side: check With cover: check Manhole: Dia: 300 mm Top connections: DN100, DN25, DN40 (2x) Outlet: DN80 With jacket: check Half coil jacketed: check Max. temperature: 0/100 °C With anchor stirrer: check (with scrapers) Speed mixing shaft: 117 rpm With homogeniser: check (Zoatec IL2, 160mm, 600-4000rpm) merk: Zoatec General Pressure Main Features Specified Features - Processing vessel
About this machine
This Zoatec Prozessbehaelter 600 is a used tank and container — a closed, jacketed processing vessel — designed for mixing, heating, cooling, and homogenising liquid and semi-liquid products under controlled pressure and temperature conditions. Vessels of this type are widely used in the food, beverage, dairy, pharmaceutical, and chemical processing industries, where precise process control within a sealed environment is essential.
The vessel is manufactured by Zoatec and is located in Barneveld, Netherlands, with a build year of 2013. It carries serial number . The vessel is constructed entirely from stainless steel, offering the corrosion resistance and hygienic properties required for process applications. The nominal volume is 600 litres, with a maximum capacity of 890 litres. The vessel body measures 1,000 mm in diameter by 1,350 mm in height.
The vessel operates at a working pressure of 3 bar, with vacuum capability on the main vessel. The jacket likewise operates at a working pressure of 3 bar, with vacuum also possible on the jacket side. The maximum working temperature range is 0 to 100 °C. The jacket is of half-coil construction, which allows efficient heat transfer through circulating media such as hot water or steam. The vessel features a conical bottom to facilitate complete drainage and a dished top, with a cover fitted as standard.
Access is provided via a 300 mm diameter manhole on the top. Top connections include a DN100 port, a DN25 port, and two DN40 ports. The outlet is sized at DN80.
Agitation is provided by an anchor stirrer fitted with scrapers, which ensures effective wall-to-wall mixing and prevents product from adhering to the vessel interior. The mixing shaft runs at 117 rpm. In addition, the vessel is equipped with a Zoatec IL2 inline homogeniser with a rotor diameter of 160 mm, capable of operating across a speed range of 600 to 4,000 rpm, allowing fine particle size reduction and emulsification within the same vessel.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
