1993 - 3C France 4420 Ltr – Pressure vessel Tank Container()
- Listing No
- 1179751
- Year
- 1993
- Manufacturer
- Model
- Condition
- Used
- Location
- Netherlands
- Price
- POA
- Description
-
Location: Barneveld No: 3104 Working pressure: 3 Bar Material: Stainless steel 1.4404 Volume: 4420 Ltr Pressure: 3 Bar Capacity: 4420 ltr Vessel sizes: 1800x2000 mm Dished top: check Dished bottom: check Manhole: 400 mm Top connections: DN 50 (3x), DN 25 Outlet: DN 50 Max. temperature: 20 °C ( operating temperature) Mounted on legs: check Floorspace: 1,9x1,9 m Total height: 2,9 m Extra Specifications: side connections 27 mm (2x), 107 mm (3x) merk: 3C France General Pressure Main Features Specified Features - Pressure vessel Information
About this machine
This 3C France 4420 Ltr is a used pressure vessel — sometimes referred to as a pressure tank or pressure container — designed to store and contain liquids or gases under controlled pressure conditions. Such vessels are widely used across the food and beverage, chemical, pharmaceutical, and industrial processing industries wherever pressurised storage or processing of fluids is required.
Built in 1993 and currently located in Barneveld, Netherlands, this unit is constructed from stainless steel grade 1.4404, a high-quality austenitic alloy well regarded for its corrosion resistance and suitability for demanding process environments. The vessel has a total volume and capacity of 4,420 litres, with a cylindrical body measuring 1,800 mm in diameter and 2,000 mm in height. Both the top and bottom ends are dished, a design that distributes pressure evenly across the structure and is standard practice in pressure vessel engineering.
The vessel is rated for a working pressure of 3 Bar, with a maximum operating temperature of 20 °C. It is fitted with a 400 mm manhole, providing access for inspection and cleaning. Connection options are extensive: the top features three DN 50 ports and one DN 25 port, while a DN 50 outlet is provided at the bottom. Side connections include two ports of 27 mm and three ports of 107 mm, offering considerable flexibility for integration into existing process pipework.
The vessel is mounted on legs, giving it a stable, self-supporting installation footprint of 1.9 × 1.9 metres, with a total height of 2.9 metres. The unit carries internal reference number 3104 and is offered in used condition.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
