1985 - Estrella AG (CH) Tank Container()
- Listing No
- 1179798
- Year
- 1985
- Manufacturer
- Model
- Condition
- Used
- Location
- Netherlands
- Price
- POA
- Description
-
Location: Barneveld Type: 1280 Ltr No: 84170 Working pressure: 3.2 Bar Vacuum possible: check Working pressure jacket: 6 Bar Material: Glass - Enamel Volume: 1280 Ltr Pressure: 3.2 Bar Vacuum: check Capacity: 1280 Ltr (nett.1000 Ltr) Vessel sizes: dia.1000x1810mm Dished top: check Dished bottom: check With cover: check Top connections: DN200 (2x), DN100 (2x), DN80 (3x) Outlet: DN80 Max. temperature: 100 degr. C With jacket: (135 ltr) With propellor stirrer: check Motor: 1 kW, 220/380 Volt (EX) Speed mixing shaft: 571 rpm Total height: 3,1 M Floorspace: 1.3x 1.3 M ATEX compatible: check merk: Estrella AG (CH) General Pressure Main Features Specified Features - Pressure vessel Information
About this machine
This Estrella AG (CH) Tank Container is a used tank container — sometimes referred to as a pressure vessel — dating from 1985 and currently located in Barneveld, Netherlands. Tank containers of this type are used in chemical, food, pharmaceutical, and related process industries for the storage, mixing, and transport of liquids under controlled pressure and temperature conditions.
The vessel has a net capacity of 1,000 litres, with a gross volume of 1,280 litres, and is constructed from glass-enamel lined material, making it suitable for applications where corrosion resistance and product purity are important. The cylindrical body measures 1,000 mm in diameter by 1,810 mm in height, with both a dished top and a dished bottom, and is fitted with a cover. Overall height of the unit is 3.1 metres, and its floor footprint is 1.3 × 1.3 metres.
The vessel is rated for a working pressure of 3.2 bar and is capable of vacuum operation. It is equipped with a heating or cooling jacket of 135 litres capacity, rated to a working pressure of 6 bar. Maximum operating temperature is 100 °C. The top of the vessel carries multiple process connections: two DN200 nozzles, two DN100 nozzles, and three DN80 nozzles, with a further DN80 outlet at the base.
Mixing is provided by a propeller stirrer driven by a 1 kW explosion-proof (EX) motor running on 220/380 V, with a mixing shaft speed of 571 rpm. The unit bears serial number 84170 and is confirmed as ATEX compatible, making it suitable for use in potentially explosive atmospheres.
This description was generated automatically from the listing details and may not reflect every specification. Please confirm with the seller before purchase.
